Cisco Catalyst 8200L w/1-NIM Slot 4x 1-Gigabit Ethernet WAN Ports
- Ideal for small branch offices with cloud-based security and SASE-compliant requirements
- Easy to install and configure in any network environment
- Boasts 4GB DRAM default memory, upgradable to 8GB for higher scale
- Uses Intel x86 CPU and enables up to 500 Mbps IPsec traffic
- Advanced and integrated end-to-end security features
- Ships without M.2 storage, but can be extended to 16G, 32G USB or 600G M.2 Non-Volatile Memory Express (NVMe) storage
Cisco Catalyst 8200L with 1-NIM Slot 4x 1-Gigabit Ethernet WAN Ports Description
Need a secure networking device for your small branch offices? Then you need the Cisco Catalyst C8200L-1N-4T. The cloud-based security networking device is designed for routing and security functions for small businesses. It is a scalable solution ideal for SASE-compliant, cloud-based security needs. This means that the C8200L-1N-4T can meet the growing needs of your business, giving you the ability to upgrade its memory and storage capacity to adapt to these changes.
The Cisco Catalyst C8200L-1N-4T boasts an Intel x86 CPU with a default 4 GB of DRAM memory, ensuring top-notch performance for your business operations. But it does not stop there - you can upgrade to 8GB, 16 GB, and even 32GB of DRAM for even greater scale and performance when your needs change. It runs on the latest Cisco IOS XE Software Release 17.5.1 for improved performance and security. With the Cloud computing that the device offers, there is no need for an overinvestment in infrastructure.
Performance that Soars:
Cisco Catalyst C8200L-1N-4T offers the perfect cost-effective upgradeable solution for small businesses and remote branches with limited IT budgets that need an all-in-one secure networking device. The device features end-to-end segmentation, VPNs, ZBFW, PKI, Cisco DNA Layer Security, and SIG for comprehensive protection. Cloud-based security helps reduce the complexity of managing on-premises security hardware. It also offers centralised management, automatic updates and the ability to scale security as needed.
Seamless Connectivity:
The C8200L-1N-4T makes sure that your branch stays connected with flexible connectivity options you can choose from. It has four 1 Gigabit Ethernet WAN ports and one NIM slot. Plus, it allows up to 500 Mbps of IPsec traffic, which keeps your data safe for fast and easy communication.
What's In The Box?
- Cisco Catalyst C8200L-1N-4T Main Unit
Cisco Catalyst 8200L Specifications
General:
- C8200L 1RU w/ 1 NIM slot and 4x 1 Gigabit Ethernet WAN ports
- Form Factor: Rack-mountable
- 1G port density: 4
- Slots: 1 NIM, 1 PIM
- Memory (DRAM) default: 4 GB
- Storage (M.2 SSD) default: No
Platform Performance:
SD-WAN Performance:
- SD-WAN IPsec throughput (1400 bytes): Up to 500 Mbps
- SD-WAN IPsec throughput (IMIX*): 400 Mbps
- SD-WAN overlay tunnels scale: 1500
Non SD-WAN) performance:
- IPv4 forwarding throughput (1400 bytes): Up to 3.8 Gbps
- IPsec throughput (1400 bytes): Up to 500 Mbps
- Number of IPsec Static Virtual Tunnel Interface (SVTI) tunnels: 1500
Non-SD-WAN system scalability:
- Number of Access Control Lists (ACLs) per system: 4000
- Number of IPv4 Access Control Entries (ACEs) per system: 72,000
- Number of IPv4 routes:800,000 with default 4 GB, up to 4M with 32 GB
- Number of IPv6 routes: 800,000 with default 4 GB, up to 4M with 32 GB
- Number of queues: 16,000
- Number of Network Address Translation (NAT) sessions: 600,000 with default 4 GB, up to 2M with 32 GB
- Number of firewall sessions: 512,000
- Number of Virtual Route Forwarding (VRF) instances: 2000
Minimum software requirements:
- Cisco Catalyst 8200 Series Edge Platform: Cisco IOS XE Software Release 17.5.1
- Security: Built-in end-to-end segmentation (VPNs), ZBFW, PKI, Cisco DNA Layer Security, SIG
Mechanical Specification:
- Dimensions (H x W x D): 1.73 x 17.25 x 11.8 in. (4.39 x 43.81 x 29.97 cm)
- Rack Units (RU): 1RU
- Chassis weight: 10 lb (4.54 kg)
- Input voltage: AC: 90 to 264 VAC
- Operating temperature: 32° to 104°F, (0° to 40°C)
- Storage temperature: -40° to 150°F, (-40° to 70°C)
- Acoustics, both models: Sound pressure (Typical/maximum) 54 dBA/69 dBA
- Acoustics, both models: Sound power (Typical/maximum) 68 dBA/80 dBA
- Relative humidity operating and nonoperating noncondensing: Ambient (noncondensing) Operating: 5% to 85%, Ambient (noncondensing) nonoperating and storage: 5% to 95%
- Altitude: 0 to 10,000 feet (0 to 3050 metres)
- Mean Time Between Failures (MTBF): 692,577 hours.
More Information
| Delivery Option | 15-20 Working Days |
|---|---|
| SKU | C8200L-1N-4T |
| Brands | Cisco |
| Networking Type | Wired Router |
| Form Factor | 1U Rackmount |
| Connectivity | Wired |
| Ports | 4x 10/100/1000Mbps LAN |
| Antenna | None |
| Condition | New |
