Cisco ISR 4351 AX Router Bundle w/ APP.SEC lic
- 4GB Flash Memory
- Software-defined WAN Platform
- 3x Gigabit Ethernet ports, 2 RJ-45 connectors (GE 0/0/0, GE 0/0/1, GE 0/0/2), auto-MDIX
- Consolidates Network, Compute, and Storage Resources
- Dynamically Routes Traffic Across the "Best" Link
- Supports Fast Ethernet, Gigabit Ethernet, IPSec, DHCP, Ethernet Networking
- Remote Management over SNMP, RMON.
Cisco ISR4351-AX/K9 Router Description
The Cisco ISR4351-AX/K9 is the Cisco ISR 4351 AX Bundle with APP.SEC Lic. It is a networking solution that delivers 200 Mbps speed. It features Application Experience with GigE, three WAN ports to provide you with a faster, more reliable network since it also connects through ethernet.
SM Slots:
It has 2 single-wide SM slots that can be converted into one double-wide SM slot, three single-wide NIM slots that can be converted into one double-wide (NIM1 and NIM2), and one single-wide NIM slot (NIM3).
Easy Management:
The Cisco ISR4351-AX/K9 can be managed and installed remotely. You don't have to hire on-site IT professionals. This can save you money while keeping the work done efficiently.
Features Cisco SD-WAN:
It has a Software-defined WAN Platform that gives you the ability to manage all aspects of your WAN from an integrated dashboard, allowing you to connect to cloud platforms more quickly, efficiently, and reliably
What's In The Box?
- Cisco 4351 Integrated Services Router with App Security License
- Mounting Hardware.
Cisco ISR 4351 AX Router Specifications
General
- Cisco ISR 4351 AX Bundle w/ APP.SEC Lic
- Aggregate Throughput: 200 Mbps to 400 Mbps
- Total onboard WAN or LAN 10/100/1000 ports:3
- RJ-45-based ports: 3
- SFP-based ports: 3
- Enhanced service-module slots: 2
- Doublewide service-module slots: 1 (assumes no single-wide SM-X modules installed)
- NIM slots: 3
- OIR (all I/O modules): Yes
- Onboard ISC slot: 1
- Default memory double-data-rate 3 (DDR3) error-correction-code (ECC) DRAM (Combined control/services/data planes): 4 GB
- Maximum memory DDR3 ECC DRAM (Combined control/services/data planes): 16 GB
- Default flash memory: 4 GB
- Maximum flash memory: 16 GB
- External USB 2.0 slots (type A): 2
- USB console port -type B mini (up to 115.2 kbps): 1
- Serial console port - RJ45 (up to 115.2 kbps): 1
- Serial auxiliary port - RJ45 (up to 115.2 kbps): 1
- Power-supply options: Internal: AC, DC, and PoE
- AC input voltage: 100 to 240 VAC auto-ranging
- AC input frequency: 47 to 63 Hz
- AC input current range, AC power supply (maximum): 7.1 to 3.0A
- AC input surge current: 60 A peak and less than 12 Arms per half cycle
- Typical power (no modules) (watts): 48
- Maximum power with AC power supply (watts): 430
- Maximum power with PoE power supply (platform only) (watts): 990
- Maximum endpoint PoE power available from PoE power supply (watts): 500
More Information
| Delivery Option | Same/Next Day Delivery |
|---|---|
| SKU | ISR4351-AX/K9 |
| Brands | Cisco |
| Networking Type | Wired Router |
| Connectivity | Wired |
| Ports | 3x 10/100/1000Mbps LAN |
| Antenna | 2 |
| Colour | Black |
| Condition | New |
