Cisco SF110D-16HP 110 Series 16-Port Unmanaged PoE Network Switch
- Offers 3.2 Gb/s Switching Capacity
- Optimises power usage to lower the cost of operation
- Offers Quality of service (QoS), loop detection, and cable diagnostics
- Connects Ethernet-enabled devices such as access points, hubs, computers, and more to a larger network and Internet
- Comes with sixteen Ethernet ports for fast, dependable network connections
- Eight ports enable Power over Ethernet for powering a variety of compatible network devices
- Supports Fast Ethernet rates, offering a high level of capacity and performance
- Deploy in a rack and start increasing your network's capacity immediately with plug-and-play configuration
Cisco SF110D-16HP Unmanaged Switch Description
The Cisco SF110D-16HP-NA 16-Port Unmanaged PoE Network Switch connects Ethernet-enabled devices such as access points, computers, hubs, and more to a larger network and the Internet. It has sixteen Ethernet ports for fast, dependable network connections, and eight of the ports enable Power over Ethernet for powering a variety of compatible network devices.
With plug-and-play configuration, you can deploy it in a rack and start increasing your network's capacity immediately. A 3.2 Gb/s switching capacity and a 1.4 Mpps forwarding capacity guarantee consumers increased bandwidth and throughput to transmit packets through the switch more quickly and effectively. This Cisco switch supports the 802.3az networking standard, which puts unused links within the switch to sleep, and as a result, helps to minimise energy usage.
With the performance of this Cisco SF110D-16HP-NA switch, commercial applications, including bandwidth-intensive video services, can run smoothly and sluggish networks can be avoided. It supports Fast Ethernet rates, unleashing a new level of capacity and performance in your business network and letting you transfer massive files in seconds.
Energy Efficient
By maximising power utilisation without sacrificing performance, the Cisco SF110D-16HP-NA switch is made to help with energy conservation, protecting the environment, and lowering your energy expenditures. Moreover, it complies with the IEEE 802.3az standard for Energy Efficient Ethernet, which lowers energy usage by keeping track of the volume of traffic on an active link and putting it to sleep during quiet times. The majority of the switches work quietly and unobtrusively without fans, which lowers energy expenditures.
Cutting-edge Technology
It has sophisticated Cisco traffic-handling technologies to keep your applications running at top performance. Damaged packets are quickly detected through fast store-and-forward switching, which stops them from propagating through the network. None of these features require management or configuration to operate; they all operate automatically. To enhance the performance of your network, integrated QoS intelligence automatically gives delay-sensitive services like phone or video priority. Network cabling defects and issues can be rapidly found and resolved with the use of cable diagnostics. By identifying loops in the network that you might have unintentionally created, loop detection helps you prevent broadcast storms from paralysing your network.
What’s in the Box?
- Cisco SF110D-16HP-NA Main Unit
Cisco SF110D-16HP Specifications
Performance
- Switching Capacity: 3.2 Gbps
- Forwarding Capacity: 1.4 mpps
- Forwarding Rate: 1.4 Mpps
Security
- Head-of-Line (HOL) Blocking: HOL blocking prevention
- Security Features: Kensington Lock Support
- Jumbo Frame: 9216 bytes
- QoS (Quality of Service): 802.1p priority based, 4 hardware queues, priority queuing, and weighted round-robin (WRR)
Standards
- Supported IEEE Standards : 802.1p, 802.3, 802.3ab, 802.3u, 802.3x, 802.3z
- Loop Detection: Helps discover loops in the network to avoid broadcast storms
- Cable Diagnostics: Quickly identify and troubleshoot network cable faults and/or shorts
Interfaces
- Cabling Type: Category 5e or better
- Inputs/Outputs: 8 x 10/100 Mb/s Ethernet (RJ45)
8 x 10/100 Mb/s Ethernet (RJ45) PoE
- LED Indicators: System/PWR, link/activity, 100M, cable diagnostics, loop detection, gigabit
Computer
- Flash Memory: 128 MB
- Operating Humidity : 10 to 90%, relative, non-condensing
- Storage Humidity: 5 to 90%, relative, non-condensing
Protocols
- Ports: 16 x RJ-45 connectors for 10BASE-T/100BASE-TX/ PoE ports
- Power Over Ethernet (PoE) Support:
Power Dedicated to PoE: 64 watts
Number of PoE Ports: 8
- Power Supply: 110-240 VAC; 50/60 Hz (internal, universal)
- Supported Protocols: Head-of-Line (HOL) Blocking
- System Memory: 128-MB RAM, 128-MB Flash
- Queuing: Weighted Round Robin (WRR)
- Jumbo Frames Support: 9216 Bytes
- Kensington Lock Support: Yes
Environmental
- Switching Bandwidth: 3.2 Gb/s
- Operating Temperature: 32 to 104°F (0 to 40°C)
- Storage Temperature: -4 to 158°F (-20 to 70°C)
- Operating Temperature: 32 to 104°F / 0 to 40°C
- Operating Humidity : 10 to 90%
- Storage Temperature: -4 to 158°F / -20 to 70°C
- Storage Humidity: 5 to 90%
Electrical
- Minimum Requirements: Devices supporting 802.3 Ethernet, 802.u Faster Ethernet, or 802.3ab Gigabit Ethernet
Cat5 or better Ethernet cable
Network interface card for each computer
- AC Input Power: 110 to 240 VAC, 50 / 60 Hz
- PoE Power Budget: 64 W
Certifications
- CE, CSA, FCC-A, UL
General
- Mounting Options: Rack-mount
- Memory: 128 MB
- Compliance and Certification: UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A
- Indicator Lights: Diagnostic, Link/Activity, System/Power
- Dimensions: 6.3 x 3.5 x 1.7" / 160 x 90 x 43 mm
- Weight: 0.99 lb (0.45 kg)
More Information
| Delivery Option | Same/Next Day Delivery |
|---|---|
| SKU | SF110D-16HP-NA |
| Brands | Cisco |
| Networking Type | Switch |
| Form Factor | Managed (No) |
| Connectivity | Wired |
| Ports | 16x 10/100 Mb/s Ethernet (RJ45) |
| Standard | IEEE 802.3af (Power over Ethernet) |
| Antenna | 2 |
| Colour | Black |
| Condition | New |
