Sony ECM88BPT - Miniature Omni-Directional Lavalier Microphone
- Ideally suited for quality-critical applications in broadcasting, theatre, and field
- Features an omnidirectional polar pattern
- Guarantees a high sonic character with a wide frequency response
- Offers an extremely low handling noise with unparalleled high sound quality
- Supplied with an unterminated “Pig Tail” connection and a cable length of 8.2 feet
- Designed in a water-resistant and miniature design
Sony ECM88BPT Miniature Omni-Directional Lavalier Microphone Description
The ECM-88BPT is a miniature omnidirectional lavalier microphone from Sony, designed to be ideally suited for quality critical applications in broadcasting, theatre, and field production. The microphone features an omnidirectional polar pattern that picks up equally from all directions since it has the same 360-degree output, regardless of its orientation to the sound source. This microphone guarantees a high sonic character with a flat and wide frequency response of 20 Hz to 20 kHz. The ECM-88BPT microphone offers an extremely low handling noise with unparalleled high sound quality. The microphone has an unterminated “Pig Tail” connector end, enabling users to attach custom connections with desired transmitters and power supplies and a cable length of 8.2 feet. Designed in a water-resistant and miniature design, the microphone is protected against moisture and remains inconspicuous when attached to clothing with the included vertical and horizontal tie clip.
High Sonic Character
The ECM88BPT microphone condenser element provides a wide, flat frequency response and high dynamic range, resulting in clean, quiet recordings. The microphone also features an omnidirectional polar pattern that picks up audio equally throughout a 360-degree space. With this, audio can be conveniently picked from every sound source in the application room.
Miniature Design
The Sony ECM88BPT microphone is designed in an ultra-miniature design that provides a considerable level of concealment needed for the stage and on-camera application. The microphone can be easily attached to clothing with the included vertical and horizontal tie clip that makes the microphone remain out of sight thanks to its small size.
What's In The Box?
- Sony ECM88BPT - Miniature Omnidirectional Lavalier Microphone
- Urethane Type Windscreen
- Single/Vertical Type Tie Clip
- Single/Horizontal Type Tie Clip
- Ferrite Clamp
Sony ECM88BPT Specifications
Audio Section
Capsule Type
- Electret Condenser
Frequency Response
- 20 Hz to 20 kHz
Directivity
- Omnidirectional
Sensitivity
- -39.0 dB (11.2 mV)
Output Impedance
- 2.5kΩ±30%, Unbalanced
Dynamic Range
- 99 dB or more
Signal-to-Noise Ratio
- 68 dB or more
Inherent Noise
- 26 dB SPL or less
Induction Noise From External Magnetic Field
- 5 dB SPL or less
Wind Noise
- 45 dB SPL or less (with supplied windscreen)
Maximum Input Sound Pressure Level
- 125 dB SPL
General Section
Connector
- No connector (pigtail)
Mic Cable
- 8.2 feet
- 2.5 m
Power Requirements
- DC 1.1 V to 10.0 V
Power Consumption
- 0.4 mA or less
Dimensions
- φ5/32 x 11/16 inches (Mic head)
- φ3.5 x 16.8 mm (Mic head)
Mass
- Approx. 0.7 oz
- Approx. 0.5 g
Supplied Accessories
- Urethane type windscreen (1)
- Single/vertical type tie clip (1)
- Single/horizontal type tie clip (1)
- Operating instructions (1)
- Ferrite clamp (1)
Optional Accessories
- Windscreen pack
- Vertical clip pack
- Safety clip pack
- Horizontal clip pack
- Accessories Double clip pack
- Colour windscreen pack
- Black windscreen pack
- Accessory kit
More Information
| Delivery Option | 15-20 Working Days |
|---|---|
| SKU | ECM-88BPT |
| Accessories Brand | Sony |
| Accessories Type | Microphone |
| Connection Type | Wired |
| Meeting Solutions | UC |
| Condition | New |
