- Designed for the Audix Dante AES67 microphone system
- Delivers Hi-Output that allows for distance miking
- Optimised for voice recognition
- Features a two-colour LED status indicator
- Provides immunity from RF interference
- Supports RJ45 connectors for plug-and-play use
Audix M55WD Hanging Ceiling Microphone Description
The M55WD microphone from Audix is a hanging ceiling microphone designed for the Audix Dante AES67 integrated microphone system (sold separately). The microphone delivers Hi-output that allows for distance miking in video teleconferencing, distance learning, boardrooms, surveillance, hospital and medical procedures, and ambient room miking applications. It is also optimised for voice recognition, providing quality audio at the DSP, and features a two-colour LED status indicator. The signal output is balanced to eliminate RF interference caused by cell phones and mobile devices. The microphone is supported by RJ45 connectors through a single Cat 5 to Cat 7 at both interfaces. Installing the M55WD requires just one 5/8" hole in the ceiling, with no additional tools needed. The M55WD eliminates wiring errors, accelerates installation, and allows all microphone gain structures to be optimised.
Dante AES67 System
The Audix Dante AES67 Integrated Microphone System featured in the M55WD microphone helps deliver high-quality audio and all microphone functions. The Dante system offers microphone functions such as on-off contact closure and LED status indicators – through a single CAT5 – CAT7 cable with RJ45 connections at both the interface and microphone.
Quick Installation process
The M55WD microphone offers a quick installation process that makes it easy to install without drilling a hole in your conference or application room ceiling. An optional aiming clip (MCHANGER) easily makes any additional angular adjustments. The mounting hardware adjusts the hanging height up to four feet from the ceiling surface without removing ceiling tiles and allows for fingertip height adjustment and rotation control.
What's In The Box?
- Audix M55WD Hanging Ceiling Microphone
- 1.56 mm / 0.063 inch Seismic and Fire Cable Restraint
Audix M55WD Specifications
Transducer Type
- Condenser
Frequency Response
- 60 Hz – 10 kHz
Polar Pattern
- Cardioid
Output Impedance
- 150 Ohms
Sensitivity
- 38 mV
Signal-to-Noise Ratio
- 72 dB
Maximum SPL
- ≥130 dB
Power Requirements
- 18 – 52 V phantom
Dynamic Range
- 108 dB
Connector
- RJ45
Materials / Finish
- White finish
Weight
- 70 g / 2.4 oz (Mic & Cable)
More Information
| Delivery Option | 15-20 Working Days |
|---|---|
| SKU | M55WD |
| Accessories Brand | Audix |
| Accessories Type | Microphone |
| Connection Type | Wired |
| Meeting Solutions | UC |
| Colour | White |
| Condition | New |
