- Identifies thousands of applications inside network traffic for deep inspection and granular policy enforcement
- Stops and detects known and unknown attacks, utilising continuous threat intelligence from AI-powered FortiGuard Labs security services
- Protects against exploits, malware, and malicious websites in both encrypted and non-encrypted traffic
- Analyses the deployment and highlights best practices to improve the overall security posture through the predefined compliance checklist
- Provides a flexible combination of various high-speed interfaces to enable the best TCO for customers
FortiGate 81E Firewall Description
The Fortinet FortiGate 81E Firewall is a compact security appliance that offers a secure SD-WAN solution in a small fanless desktop form factor. With industry-leading secure SD-WAN and system-on-a-chip acceleration, it defends cyber threats in a cost-effective and simple-to-install solution. Through its security-driven networking strategy, Fortinet offers a tight network-to-new-security-generation integration.
USB connection on the Fortinet FortiGate 81E Firewall enables you to seamlessly connect a 3G/4G USB modem from a compatible third party, adding extra WAN connectivity or a redundant link for maximum reliability. The examination is sped up using Fortinet's ninth-generation custom SPU CP9 content processor, which operates away from the mainstream of traffic.
FortiOS, the company's leading operating system, enables the Fortinet Security Fabric to combine high-performance networking with security, resulting in a uniform and context-aware security posture across network endpoints and clouds. The unified approach and naturally developed best-of-breed capabilities enable corporations to operate without sacrificing performance or protection, while also making it easier for people to consume new ideas.
FortiGuard Security Services
In addition to providing thorough security upgrades for the whole portfolio of Fortinet solutions, FortiGuard Labs provides real-time intelligence on the threat landscape. To deliver the greatest generation of protection, the team—which consists of engineers, security threat researchers, and forensic specialists—works with law enforcement agencies, other network and security organisations, and the top threat monitoring companies around the globe.
What’s in the Box?
- Fortinet FortiGate 81E Firewall Main Unit
FortiGate 81E Specs
System Performance and Capacity
- Firewall Throughput (1518 / 512 / 64 byte UDP packets): 4 / 4 / 4 Gbps
- Firewall Throughput (Packet per Second): 6 Mpps
- Firewall Latency (64 byte UDP Packets): 3 μs
- New Sessions/Second (TCP): 30,000
- Concurrent Sessions (TCP): 1.3 Million
- IPsec VPN Throughput (512 byte): 2.5 Gbps
- Firewall Policies: 5,000
- Client-to-Gateway IPsec VPN Tunnels: 2,500
- Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode): 200
- Gateway-to-Gateway IPsec VPN Tunnels: 200
- SSL Inspection Throughput (IPS, avg. HTTPS): 135 Mbps
- SSL-VPN Throughput: 200 Mbps
- SSL Inspection Concurrent Session (IPS, avg. HTTPS): 95,000
- SSL Inspection CPS (IPS, avg. HTTPS): 135
- CAPWAP Throughput (HTTP 64K): 920 Mbps
- Application Control Throughput (HTTP 64K): 900 Mbps
- Virtual Domains (Default / Maximum): 10 / 10
- Maximum Number of FortiAPs (Total / Tunnel Mode): 32 / 16
- Maximum Number of FortiTokens: 500
- Maximum Number of Switches Supported: 8
- Maximum Number of Registered FortiClients: 200
- High Availability Configurations: Active / Active, Active / Passive, Clustering
System Performance
- Threat Protection Throughput:250 Mbps
- NGFW Throughput: 360 Mbps
- IPS Throughput: 450 Mbps
Hardware
- USB Ports: 1
- Internal Storage: 1x 128 GB SSD
- GE RJ45 Ports: 14
- GE RJ45/SFP Shared Media Pairs: 2
- GE RJ45 DMZ/HA Ports: 2
- Console (RJ45): 1
Operating Environment and Certifications
- Storage Temperature: -31–158°F (-35–70°C)
- Operating Temperature: 32–104°F (0–40°C)
- Humidity: 10–90% non-condensing
- Operating Altitude: Up to 16,404 ft (5,000 m)
- Noise Level: Fanless 0 dBA
- Compliance: FCC Part 15B, Class B, CE, RCM, VCCI, UL/cUL, CB, BSMI
- Certifications: ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN
Dimensions and Power
- Form Factor: Desktop
- Power Required: 100–240V AC, 50–60 Hz
- Power Consumption (Average / Maximum): 20 W / 72 W
- Current (Maximum): 100V AC / 0.7A, 240V AC / 0.3A
- Heat Dissipation: 245.67 BTH/h
- Height x Width x Length: 1.65 x 8.5 x 7 inches / 42 x 216 x 178 mm
More Information
| Delivery Option | Same/Next Day Delivery |
|---|---|
| SKU | FG-81E |
| Brands | Fortinet |
| Networking Type | Firewalls |
| Connectivity | Wired, Ethernet |
| Ports | 1x 10/100Mbps |
| Antenna | 2 |
| Colour | White |
| Condition | New |
