Fortinet FortiGate FG 100E Network Security/Firewall Appliance
Buy together
- Suitable for medium to large-sized enterprise deployment
- Secured SD-WANsolution
- Firewall performance for IPv4/IPv6, SCTP, and multi-cast traffic
- VPN, CAPWAP, and IP tunnel acceleration
- Integrate with advanced layer 7 security and virtual domains (VDOMs)
Fortinet FortiGate FG 100E Description
For mid-sized to large businesses deployed at the campus or corporate branch level, the FortiGate 100E series offers an application-centric, secure, scalable SD-WAN solution with next-generation firewall (NGFW) features. It provides industry-leading secure SD-WAN protection in a straightforward, inexpensive, and quick-to-deploy solution. The Security-Driven Networking methodology used by Fortinet offers a tight network connection with the next security generation.
Performance:
Using specially designed security processor (SPU) technology, the Fortinet 100E provides the best and industry-leading threat protection performance for SSL encrypted traffic and Ultra-low latency.
Security:
In both encrypted and unencrypted traffic, Fortinet 100E detects thousands of applications for deep inspection and granular policy enforcement, shielding them against malware, exploits, and harmful websites. Additionally, leveraging ongoing threat intelligence from AI-powered FortiGuard Labs security services, it detects and prevents known and unknown threats.
Management:
The management console that comes with the Fortinet 100E is efficient, easy to use, and offers thorough network automation and visibility with Zero Touch Integration with Fortinet's Security.
What’s In The Box?
- Fortinet FG-100E Main Unit
- Ethernet Cable
- Power Cable
- Quick Start Guide
Fortinet FG 100E Specificaions
Interfaces and Modules
- GE RJ45 Ports: 14
- GE RJ45 Management/HA/DMZ Ports: 1 / 2 / 1
- GE SFP Slots: No
- GE RJ45 PoE/+ Ports: No
- GE RJ45 WAN Ports: 2
- GE RJ45 or SFP Shared Ports: 2
- USB Port: 1
- Console Port: 1
- Internal Storage: No
- Included Transceivers: 0
System Performance and Capacity
- Firewall Throughput (1518 / 512 / 64 byte, UDP): 7.4 / 7.4 / 4.4 Gbps
- Firewall Latency (64 byte, UDP): 3 μs
- Firewall Throughput (Packet per Second): 6.6 Mpps
- Concurrent Sessions (TCP): 2 Million
- New Sessions/Second (TCP): 30,000
- Firewall Policies: 10,000
- IPsec VPN Throughput (512 byte): 4 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels: 2,000
- Client-to-Gateway IPsec VPN Tunnels: 10,000
- SSL-VPN Throughput: 250 Mbps
- Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode): 500
- SSL Inspection Throughput (IPS, avg. HTTPS): 130 Mbps
- SSL Inspection CPS (IPS, avg. HTTPS): 130
- Application Control Throughput (HTTP 64K): 1 Gbps
- CAPWAP Throughput (1444 byte, UDP): 1.5 Gbps
- Virtual Domains (Default / Maximum): 10 / 10
- Maximum Number of FortiSwitches Supported: 24
- Maximum Number of FortiAPs (Total / Tunnel): 64 / 32
- Maximum Number of FortiTokens: 5,000
- Maximum Number of Registered FortiClients: 600
- High Availability Configurations: Active / Active, Active / Passive, Clustering
System Performance — Enterprise Traffic Mix
- IPS Throughput: 500 Mbps
- NGFW Throughput: 360 Mbps
- Threat Protection Throughput: 250 Mbps
Dimensions and Power
- Height x Width x Length: 1.75 x 17 x 10 inches/44.45 x 432 x 254 mm
- Form Factor: Rack Mount, 1 RU
- AC Power Supply: 100–240V AC, 60–50 Hz
- Power Consumption (Average / Maximum): 23.0 W / 25.5 W
- Heat Dissipation: 87.0 BTU/h
More Information
| Delivery Option | Same/Next Day Delivery |
|---|---|
| SKU | P188270418 |
| Brands | Fortinet |
| Networking Type | Firewalls |
| Form Factor | Rack-mountable |
| Connectivity | Wired |
| Ports | 1x 10/100Mbps |
| Antenna | None |
| Colour | Black |
| Condition | New |
