HP Scanjet 4570c Digital Flatbed Scanner

HP Scanjet 4570c Specifications

General

• Scanner Type: flatbed, one-pass colour, and monochrome
• Input Modes: front panel “scan,” “copy,” e-mail,” “share-to-web” “HP memories disc creator launch,” buttons, HP Photo & Imaging software, from software applications via TWAIN 1.8, transparent material adapter for scanning 35mm negatives/slides, optional automatic photo feeder for scanning stacks of 3x5 or 4x6-inch photos
• Additional Features: “power save,” “cancel,” “copy quantity,” “print colour/b&w” buttons, 2-character LCD
• Preview Speed: 7 seconds
• Imaging Technology: charge-coupled device (CCD)
• Light Source used when Scanning: cold cathode fluorescent
• Bit Depth: 48-bit colour (internal hardware)
• Greyscale Levels: 256
• Scaling: 10 to 2000% in 1% increments (scaling range dependent upon resolution)
• Maximum Document Size: 8.5 x 11.7 in. (21.0 x 29.7 cm), optional automatic photo feeder scans 3 x 5-in and 4 x 6-in. photos
• Photographic Format Types: 35 mm film strips and mounted slides via the transparent material adapter, photos up to full scan bed size, 3x5 or 4x6-inch photos via optional automatic photo feeder
• Interface: USB 2.0 full and high speed
• Optional Automatic Photo Feeder Capacity (not included; purchase separately): up to 24 3 x 5-in. and 4 x 6-in. photos

Task Speeds

• less than 30 seconds – 4 x 6-in. colour photo into Microsoft Word
• less than 45 seconds – OCR a full page of text into Word
• less than 25 seconds – black-and-white bitmap into Word
• less than 25 seconds – e-mail a photo
• Preview and task speeds are hp measurements using a 1.7 GHz PC with 256 MB RAM

and Microsoft Windows 2000 Professional, and a USB 2.0 full-speed interface via the

hp photo & imaging software path

Resolution

• 2400-dpi optical resolution
• 2400 x 2400-dpi hardware resolution
• 99,999 dpi enhanced scan resolution

Multiple File Formats

• Windows: TIFF (.tif), TIFF compressed (.tif), Bitmap (.bmp), DCX file (.dcx), PCX file (.pcx), JPEG (.jpg), GIF file (.gif), FlashPix (.fpx), Plain Text (.txt), PDF File (.pdf), HTML file (.htm), Rich Text (.rtf)
• Macintosh: TIFF (.tif), TIFF compressed (.tif), PICT, JPEG (.jpg), GIF file (.gif), FlashPix(.fpx), PDF File (.pdf), Plain Text (.txt), HTML file (.htm), Rich Text (.rtf)

Environmental Ranges

• Operating Temperature: 50 to 95° F (10 to 35° C)
• Recommended Operating Humidity: 15-85% non-condensing
• Storage Temperature: –40 to 158° F (–40 to 70° C)
• Storage Humidity: 5–90% non-condensing 32 to 158° F (0 to 70° C)

Power Supply

• 100 – 240 VAC, 50 – 60 Hz
• 1500mA; a heating feature added to lamps to provide no warm-up time (user-selectable feature)

Power Consumption

• 21.5 watts maximum, 9 watts in sleep mode
• US EPA ENERGY STAR compliant

Operating System

• Microsoft Windows XP Professional, XP Home Edition, 2000 Professional, Me, and 98, Mac OS 9.1 and higher, Mac OS X 10.1.2 and higher

Minimum System Requirements

• CD-ROM drive, 64 MB RAM, SVGA monitor (800 x 600, 16-bit colour); USB port, HP memories disc creator software requires CD writer and 700 MB additional hard disk space
• Microsoft Windows: PC with Pentium II processor, Celeron or compatible; Microsoft

Windows XP Professional or XP Home Edition, Me, 2000 Professional or 98; 300 MB available disk space; Microsoft Windows Internet Explorer 5.0

• Mac: PowerPC processor (includes iMac); macOS 9.1 or OS X 10.1.2 or higher; 150 MB available disk space

Dimensions

• Height 3.62 in. (99 mm)
• Width 12.28 in. (312 mm)
• Depth 21.46 in. (545 mm)
• Net Weight: 8.44 lb (3.84 kg)
