Huddly and Shure Wireless Audio & Video Conferencing Solution - Medium Room
- Perfectly curated medium room solution for an unmatched meeting experience
- AI-powered camera ensures full room coverage with a 150-degree field of view
- Auto-framing technology for real-time face-to-face communication
- 90-degree camera tilt capability
- Two highly capacitive 7-inch colour display controllers for control and management
- Features integration with Sonos application
- Shure ceiling microphone and ceiling loudspeaker for an unmatched sound provision and voice pickup
- Ultra wide 4K interactive display for large format conference image display
- Comes with PoE+ powered Crestron RMC4
Huddly and Shure Wireless Audio & Video Conferencing Solution - Medium Room Description
Devices built with cutting-edge technology are curated to form this medium meeting room solution. Get the complete solution of the Huddly & Shure Wireless Audio/Video Conferencing Solution and get your meeting room transformed into a smarter conferencing space. Inside this collaboration solution, you get the Crestron UC-MM30-R tabletop conference device, the RMC4 4-Series Control System, the Crestron TS-770-W-S 7 Tabletop Touch Screen, four Shure MXN5W-C Ceiling Speaker, the MXA920 24" Ceiling Array Microphone, Huddly IQ Camera, and Dell P8624QT 86-inch 4K Interactive Touch Monitor. With the combination of all these enterprise-class devices, you have a room where you can smoothly virtually collaborate by visual and audio.
AI-Powered Conference Camera for Smooth Video Coverage
Performance is not about the size, it is about how efficiently a product can deliver and the Huddly IQ Camera typifies this. Specifically designed for conference rooms, the Huddly IQ Camera features a small form factor design but delivers more than you can imagine. This AI-powered conferencing camera captures the entire room on a large scale with its 150-degree angle of view and intelligently adjusts depending on the number of participants in the room. It smoothly performs pan, tilt, and zoom capability without distortion, and requires no complex connection. Just with a single USB cable, you are connected and ready for conferencing.
Unmatched Audio Pick Up and Delivery for Smooth Communication
This solution brings you two devices from Shure’s Audio Ecosystem, four (4x) MXN5W-C Ceiling Speaker and the MXA920 24-inch Ceiling Array Microphone. These two devices, when combined, offer you full-duplex audio collaboration, supplying you with high-pitched, intelligible sounds and directionally voice pick up of room participants. Both Shure devices are to be placed in your drop ceiling environment, helping to reduce clutter.
Portable Display Control for Room Management
The two included touchscreen control features a colour high-capacitive display screen that is 7 inches wide. The Crestron UC-MM30-R tabletop conference device is combined with high-performance speakerphones and omnidirectional microphones. Its control panel makes it easy to manage the Crestron Home operating system to provide a single convenient home office companion. Using the Crestron TS-770-W-S Tabletop Touch Screen, you can schedule meetings. Both devices are capable of performing functions such as browsing the internet, streaming videos and music, and more.
Ultrawide Screen Monitor for Touch Interaction
Get your entire team engaged in meeting collaborations through an ultrawide screen interactive display - the Dell P8624QT 86" 4K Interactive Touch Monitor. This enterprise-class monitor offers true-to-life images with its brilliant 85.6-inch 4K ultra-high-definition large screen. Multiple users can make reference to a specific point during an on-screen presentation, thanks to its 20-point touch capability for making it possible. Also, while participants interact with this intuitive touch screen, it is almost impossible for your palm to mistakenly erase as it comes built with palm rejection. The Dell P8624QT supports USB-C connectivity and comes with built-in dual 20W speakers for intelligible sound production.
Crestron RMC4 4-Series Control System
The Crestron RMC4 is a PoE+ powered device that offers a highly secured performance control processor and interface for monitoring and controlling small audio/video systems, single display devices, lighting and shading, climate control, energy management, security, and many other specialised applications. This enterprise standard comes in a compact and portable design and offers versatile attachments behind display screens and projectors.
What's in the Box?
- Crestron UC-MM30-R Tabletop Conference Device
- Power Adapter
- Crestron RMC4 4-Series Control System
- Crestron TS-770-W-S 7 in. Tabletop Touch Screen
- Shure MXN5W-C Loudspeaker 4x
- Magnetic grille with removable Shure logo
- Flexible conduit clamp
- Cover plate
- Shure MXA920 24" Ceiling Array Microphone
- Strain relief tabs (3)
- Cable ties (8)
- Rubber pad set
- Documentation
- Huddly IQ Camera for Conference Rooms Kit
- Dell P8624QT 86" 4K Interactive Touch Monitor
- 2 Styluses
- Remote Control Holder
- 3 x wire saddles
- 2 stylus nibs, 1 x PC box holder
- SuperSpeed USB Cable
- DisplayPort Cable
- USB-C Cable
- HDMI Cable
- Quick Start Guide
Huddly & Shure Audio/Video Conferencing Solution - Medium Room Specifications
Crestron UC-MM30-R
Communications
Ethernet:
- 10/100 Mbps, auto-switching, auto‑negotiating, auto-discovery, full/half duplex, DHCP, TCP/IP, UDP/IP, CIP, SSL, TLS, SSH, SFTP (SSH File Transfer Protocol), SRTP, IEEE 802.1X, Active Directory® authentication, digest access authentication, password login, Microsoft Intune® client, IEEE 802.3at Type 2 PoE+ compliant
Wi-Fi®:
- Dual-band 802.11a/b/g/n/ac (2.4 GHz and 5 GHz)
Touch Screen
- Display Type: TFT active matrix colour LCD
- Size: 7 in. (178 mm) diagonal
- Touch Screen: Capacitive, multi‑touch capable
- Resolution: 1200 x 800 pixels
- UI: Crestron Home™ OS
Buttons and Indicators
- Mic Mute Symbol: (4) Capacitive buttons with bi‑colour LEDs, toggles between mute and unmute; Green indicates unmute, red indicates mute
- Light Bar: Bi-colour LED responds to mute and unmute; Green indicates unmute, red indicates mute
Audio
- Acoustic Echo Cancellation: Automatic gain control, dynamic noise reduction, acoustic echo cancellation, full‑duplex IEEE 1329 Type 1 compliant
Speaker
- Full range speaker
- Amplifier Power: 7 W (rated power)
- Output Volume: 83 ±3 dBA @1m 1 kHz
- Frequency Response: 100 Hz - 20 kHz
Microphones
- (4) Built-in omnidirectional, digital MEMS microphones with 360° audio pickup
- Maximum pickup range: 10 ft (3 m) typical
Occupancy Sensor
- Detection Range: Approx. 10 ft (3 m) PIR range in front of touch screen
- Coverage Pattern: ±45° horizontally
Connectors
LAN:
- (1) 8‑pin RJ‑45 connector, female;
- 100BASE-TX/1000BASE-T Ethernet port;
- PoE+ PD (powered device) port;
- PoE+ injector and cables included
USB
- (1) Micro-USB Type B connector, female;
- USB 2.0 device port;
- 5.8 ft (1.8 m) USB micro-B to A cable included
Security Port
- Kensington Security Slot™ port
Power
- Power over EthernetIEEE 802.3af Class 3 and 802.3at Class 4 PoE+ powered device;
- PoE+ injector included
Dimensions
- Height: 3.02 in. (77 mm)
- Width: 7.17 in. (182 mm)
- Depth: 9.61 in. (244 mm)
- Weight: 2.1 lb (0.96 kg)
Compliance
- Regulatory Model: M201928001
- FCC Part 15 Class B, IC , CE, UL® Listed
Crestron RMC4 4-Series Control System
Control Engine
- Crestron® 4-Series™; real-time, preemptive multi-threaded/multitasking kernel; Transaction-Safe Extended FAT file system; supports up to 10 simultaneously running programmes (licence required)
Communications
- Ethernet: 100 Mbps, auto‑switching, auto‑negotiating, auto‑discovery, full/half duplex, industry-standard TCP/IP stack, UDP/IP, CIP, DHCP, SSL, TLS, SSH, SFTP (SSH File Transfer Protocol), FIPS 140-2 compliant encryption, IEEE 802.1xX, SNMP, BACnet and IP3, IPv4 or IPv6, Active Directory® service authentication, HTTPS web server, HTTPS web browser setup and XiO Cloud® client, SMTP email client
- Cresnet: Cresnet master mode
- USB: Supports computer console and USB mass storage class devices via the front panel USB OTG (On‑the‑Go) device port
- RS-232/422/485 For 2-way device control and monitoring, supports RS-232, RS-422, or RS-485 up to 115.2k baud with hardware and software handshaking
- IR/Serial: Supports 1-way device control via infrared up to 1.2 MHz or serial TTL/RS-232 (0–5 V) up to 115.2k baud
Memory
- SDRAM: 1 GB
- Flash: 8 GB
- External Storage: Supports USB mass storage devices up to 1 TB
Connectors
USB-OTG
- (1) USB Type Micro-AB female;
- USB OTG port for computer console and USB mass storage devices
LAN PoE
- (1) 8-pin RJ-45 connector, female;
- 100BASE-T Ethernet port;
- PoE (Power over Ethernet) PD (Powered Device) port
NET
- (1) 3-pin 3.5 mm detachable terminal block;
- Cresnet master port;
- Provides data only (no power)
DIGITAL IN 1–2
- (1) 3-pin 3.5 mm detachable terminal block;
- Comprises (2) digital inputs (referenced to GND);
- Voltage Range: Rated for 0–24 VDC;
- Input Impedance: 2.2k Ω pulled up to 5 V;
- Logic Threshold: >2.0 V low/0 and <1.1 V high/1
RELAY 1–2
- (1) 4-pin 3.5 mm detachable terminal block;
- Comprises (2) normally open, isolated relays;
- Rated 1 A, 30 VAC/VDC;
- MOV arc suppression across contacts
IR 1–2
- (1) 4-pin 3.5 mm detachable terminal block;
- Comprises (2) IR output ports;
- IR output up to 1.2 MHz;
- 1-way serial TTL/RS-232 (0–5 V) up to 115.2k baud;
- IRP2 IR emitters sold separately
COM
- (1) 5-pin 3.5 mm detachable terminal block;
- Bidirectional RS‑232/422/485 port;
- Up to 115.2k baud;
- Hardware and software handshaking support
G
- (1) 6-32 screw;
- Chassis ground lug
Controls and Indicators
- PWR: (1) Bicolour green/amber LED, indicates operating power is present; Amber indicates that the device is booting and is not yet ready to operate; Green indicates that the device is ready to operate
- NET: (1) Amber LED, indicates communication with Cresnet devices
- MSG: (1) Red LED, indicates processor has generated an error message
- HW-R: (1) Recessed push button, initiates hardware reset
- SW-R: (1) Recessed push button, initiates software reset
LAN PoE
- (1) Green and (1) Amber LEDs
- Green LED indicates Ethernet link status and connection speed
- Amber LED indicates Ethernet activity
Power
- Power over Ethernet: IEEE 802.3at Type 1 (802.3af compatible) Class 0 (12.95 W) PoE Powered Device
- Power Consumption: 6.5 W
NOTE: The RMC4 does not use or supply any Cresnet power.
Environmental
- Temperature: 32 to 104 °F (0 to 40 °C)
- Humidity: 10% to 90% RH (non condensing)
- Heat Dissipation: 22 BTU/hr
Construction
- Enclosure: IFE micro form factor, black and blue plastic
Mounting:
- Freestanding, stackable, surface mount, or 35 mm DIN EN 60715 rail mount;
- Occupies 8 DIN module spaces (144 mm);
- Surface/DIN rail mounting bracket included, optional rack mount and pole mount kits sold separately
Dimensions
- Height: 1.35 in (35 mm); 1.77 in (45 mm) with bracket
- Width: 5.04 in (128 mm); 5.36 in (137 mm) with bracket
- Depth: 2.86 in (73 mm)
Weight: 6.4 oz (180 g)
Compliance
Regulatory Model: RMC4;
- UL® Listed for US & Canada, CE, IC, FCC Part 15 Class B digital device
Crestron TS-770-W-S 7 in.
Touch Screen Display:
- Display Type: TFT active matrix colour LCD
- Size: 7 in. (178 mm) diagonal
- Aspect Ratio: 16:10 WXGA
- Resolution: 1280 x 800 pixels
- Brightness: 350 nits (cd/m²)
- Contrast: 850:1
- Colour Depth: 24-bit, 16.7M colours
- Illumination: Edge Lit LED with auto brightness control
- Viewing Angle: ±80° horizontal, ±80° vertical
- Touch Screen: Projected capacitive, 5-point multitouch capable
Buttons:
- Hard Keys: (6) Virtual buttons in the collapsible universal toolbar, per‑button show/hide, preconfigured with icons for Power, Home, Lights, Up, Down, and MMicrophone; optional custom programming via control system for additional functions
- Reset: (1) Pin hole on the bottom for hardware reset
Graphics Engine:
- Crestron HTML5 and Smart Graphics® software technology, multi language web browser1, multilingual on screen keyboard, screensaver, single scalable streaming video window, native room scheduling applications, native Sonos® app, native Zoom Rooms app7, native Crestron Home® OS app, setup and diagnostics via web browser, cloud, or onscreen UI
Room Scheduling Support:
- Crestron Scheduling App: Crestron Fusion® software, Microsoft Exchange Server® and Office 365® software, Google Calendar™ and G Suite™ software, CollegeNET® 25Live® software, and Ad Astra software (IBM® Notes® software is also supported through Crestron Fusion on-premises server only)4
- Third-Party Apps: Includes support for various third-party scheduling applications.
Memory:
- RAM: 2 GB LPDDR3
- Storage: Firmware/Application: 16 GB eMMC pSLC
- Maximum Project Size: 600 MB
Wired Communications:
- Ethernet: 100 Mbps, auto-switching, auto-negotiating, auto-discovery, full/half duplex, TCP/IP, UDP/IP, CIP, DHCP, SSL, TLS, SSH, SFTP (SSH File Transfer Protocol), IEEE 802.1X, SNMP, IPv4 or IPv6, Active Directory® service authentication, HTTPS web browser setup, XiO Cloud® client, IEEE 802.3at compliant
- USB: USB 2.0 host for room scheduling accessories
Wireless Communications:
- Transceiver: IEEE 802.11a/b/g/n/ac Wi-Fi (2.4 or 5 GHz 2-way RF), static IP or dynamic IP via DHCP
- Security: 64 and 128-bit WEP, WPA and WPA2-PSK with TKIP and AES
- Range: Up to 50 ft (15 m), subject to site-specific conditions
- Bluetooth® Hardware: Crestron Bluetooth beacon
Streaming Decoder:
- Video Formats: H.265, H.264 (MPEG‑4 part 10 AVC, MJPEG)
- Audio Formats: AAC stereo
- Bitrates: Up to 25 Mbps (20 Mbps maximum recommended)
- Input Resolutions: Up to 1920x1080 at 30 fps
- Protocol: RTSP
Audio:
- Features: Built-in microphone and speakers, Rava® SIP Intercom, voice recognition
- Audio Feedback Formats: MP3
Connectors:
- LAN PoE: (1) 8-pin RJ-45 connector, female, with 2 LED indicators; 100BASE-TX Ethernet port; PoE+ PD port; Green and yellow LEDs indicate Ethernet port status
- USB: (1) USB Type-A connector, female; USB 2.0 host port
Power:
- PoE (Power over Ethernet), IEEE 802.3at Type 2 compliant PoE+ PD (Powered Device);
- Requests 15 W from an 802.3at Type 2 PSE with LLDP advanced power management;
- Requests 30 W (PoE+ Class 4) from an 802.3at Type 2 PSE without LLDP;
- Requests 15.4 W (PoE Class 0) from an 802.3af (or 802.3at Type 1) PSE
Weight:
- 1.33 lb (605 g).
Shure MXN5W-C
- Connector Type: RJ45
- Power Requirements: Power over Ethernet (PoE) Class 0 or PoE Plus Class 4
- Power Consumption:
- Power over Ethernet (PoE): 12 W maximum (11 W typical)
- PoE Plus: 24 W maximum (23 W typical)
- Weight: 6.5 lbs (2.95 kg)
- Product Dimensions: H x W x D: 12 x 12 x 4 in. (304.8 x 304.8 x 101.6 mm)
- Control Software: Shure Designer
- Plenum Rating: UL 2043 (Suitable for Air Handling Spaces)
- Operating Temperature Range:−6.7°C (20°F) to 40°C (104°F)
- Storage Temperature Range:−29°C (-20°F) to 74°C (165°F)
- Frequency Response (-3 dB): 120 Hz to 20 kHz
- Maximum Output Level
At 1 metre
- Power over Ethernet (PoE): 92 dB SPL
- PoE Plus: 98 dB SPL
- Coverage Angle
- Average of 1-octave band centred on 4 kHz: 94°
- Digital Signal Processing
- Delay, Limiter, Signal Generator, Equaliser (4-band Parametric)
Latency
Not including Dante latency
- 1.5 ms
Shure MXA920
Audio
- Acoustic Echo Cancellation Tail Length: Up to 250 ms
- Frequency Response: 125 Hz to 20,000 Hz
- Bit Depth: 24
- Dynamic Range: 77.5 dB
- Self Noise: 18.24 dB SPLA
- Sampling Rate: 48 kHz
- Sensitivity at 1 kHz: −1.74 dBFS/Pa
- Maximum SPL Relative to 0 dBFS overload: 95.74 dBSPL
- Signal-to-Noise Ratio Ref. 94 dBSPL at 1 kHz: 75.76 dB A Weighted
- Latency (Does not include Dante latency)
- Direct outputs (Automatic coverage off): 15.9 ms
- Automix output (Includes IntelliMix processing): 26.6 ms
- Digital Signal Processing: Automatic mixing, acoustic echo cancellation (AEC), noise reduction, automatic gain control, compressor, delay, equaliser (4 band parametric), mute, gain (140 dB range)
Networking
- Connector Type: RJ45
- Cable Requirements: Cat5e or higher (shielded cable recommended)
General
- Coverage Type: Automatic or steerable
- Dust Protection: IEC 60529 IP5X Dust Protected
- Plenum Rating: UL2043 (Suitable for Air Handling Spaces)
- Power Consumption: 10.1 W maximum
- Power Requirements: Power over Ethernet (PoE), Class 0
- Control Software: Designer or web application
- Storage Temperature Range: −29°C (−20°F) to 74°C (165°F)
- Operating Temperature Range: −6.7°C (20°F) to 40°C (104°F)
Physical
- Weight: MXA920-S: 11.8 lbs (5.4 kg)
- Height: 2.15 in. (54.69 mm)
- Microphone flange: 0.41 in. (10.5 mm)
- Edge to edge: 23.77 in. (603.8 mm)
Huddly IQ Camera for Conference Rooms
- 1080p Full HD @ 30 fps
- 16:9 aspect ratio output
- 12 Megapixels 1/2.3” CMOS sensor
- 720p HD @ 30 fps
- UVC 1.1 plug-and-play compatible
Optics
- Ultrawide angle glass optics
- Diagonal field of view 150 ̊
- Vertical field of view 90 ̊
- Horizontal field of view 120 ̊
- f/2.8 aperture
Connectivity
- USB Type-C connector
- Power requirement 5V 900mA
- SuperSpeed USB 3
Hardware
- Aluminium unibody construction
- 5-element beamforming microphone array (optional)
- High-performance video processing engine
- Embedded mounting hinge
- Neural compute engine
- Camera tripod mount
Packaging Dimensions
- L: 80 mm x W: 52 mm x H: 50 mm
Dell P8624QT 86" 4K Interactive Touch Monitor
General:
- Product Type: LED-backlit LCD flat panel display
- Diagonal Class: 86"
- Diagonal Size: 85.6"
- Commercial Use: Yes - interactive
- Combined With: Touch screen (multi-touch)
- Power Consumption Operational: 430 Watt
- Power Consumption (On mode): 170 W
- TV Tuner: No tuner
- TV Tuner Presence: No
- Video Interface: HDMI
- HDMI Ports Qty: 4 ports
- PC Interface: DisplayPort
- Picture Enhancements: 72% Colour Gamut NTSC
- Dimensions: Without stand
- Width: 78.06 in
- Depth: 3.26 in
- Height: 45.54 in
- Weight: 191.80 lb
Display:
- LCD Display Technology: IPS
- Resolution: 3840 x 2160
- Display Format: 4K UHD (2160p)
- Image Aspect Ratio: 16:9
- Brightness: 350 cd/m²
- Viewing Angle: 178°
- Viewing Angle (Vertical): 178°
- Touchpoints Qty: 20
- Response Time: 8 ms
- Pixel Pitch: 0.4935 mm
- Colour Support: 1.07 billion colours
- Frame Rate & Enhancement Technology: 60 Hz Refresh Rate
- LCD Backlight Technology: LED backlight
- Coating: Anti-glare, 9H Hard
- Image Contrast Ratio: 1200:1
- Dynamic Contrast Ratio: 1200:1
- Additional Features: Security lock slot (cable lock sold separately); built-in USB hub
Stands & Mounts
- Flat Panel Mount Interface: 600 x 400 mm
- VESA Compatibility: Yes
Media Player
- USB Port: Yes
Remote Control
- Battery Form Factor: AAA type
- Battery Included: Yes
- Battery Included Qty: 2
- Battery Required Qty: 2
Audio System
- Speaker System: 2 speakers
- Output Power / Total: 40 Watt
- Speakers: 2 - 20 Watt
Connections
Connector Type:
- 4 x USB 3.1 downstream
- 3 x USB 3.1 upstream
- USB
- DisplayPort
- 4 x HDMI
- Audio line-out
- RS-232
- LAN
Miscellaneous:
- Security Slot Type: Kensington security slot
- Compliant Standards: RoHS
More Information
| SKU | huddly_shureaudio_microsoft_med |
|---|---|
| Resolution | 1080p |
| Room Size | Medium |
| No. of User(s) | 9-13 |
| Camera Platform Support | Windows, MAC OS |
| Motorised PTZ | No |
| AI Technology | Yes |
| Auto-Tracking | No |
| Plug and Play | Yes |
| Allows for expansion Mic | Yes |
| RightSense Technology | No |
| Conference Set | Conference solution |
| Camera Preset | 2 |
| Camera Zoom | 2x |
| HD Zoom | No |
| Mount Options | Multiple mounting options |
| Certified for Business | No |
| Control | Touch Controller |
| Meeting Solutions | Microsoft Teams® |
| USB Type | USB 2.0 |
| Frame Rate | 30fps |
| Focus Type | Auto Focused |
| Connectivity | Wired |
Reviews
Search FAQs
Questions & Answers
Huddly and Shure Wireless Audio & Video Conferencing Solution - Medium Room Description
Devices built with cutting-edge technology are curated to form this medium meeting room solution. Get the complete solution of the Huddly & Shure Wireless Audio/Video Conferencing Solution and get your meeting room transformed into a smarter conferencing space. Inside this collaboration solution, you get the Crestron UC-MM30-R tabletop conference device, the RMC4 4-Series Control System, the Crestron TS-770-W-S 7 Tabletop Touch Screen, four Shure MXN5W-C Ceiling Speaker, the MXA920 24" Ceiling Array Microphone, Huddly IQ Camera, and Dell P8624QT 86-inch 4K Interactive Touch Monitor. With the combination of all these enterprise-class devices, you have a room where you can smoothly virtually collaborate by visual and audio.
AI-Powered Conference Camera for Smooth Video Coverage
Performance is not about the size, it is about how efficiently a product can deliver and the Huddly IQ Camera typifies this. Specifically designed for conference rooms, the Huddly IQ Camera features a small form factor design but delivers more than you can imagine. This AI-powered conferencing camera captures the entire room on a large scale with its 150-degree angle of view and intelligently adjusts depending on the number of participants in the room. It smoothly performs pan, tilt, and zoom capability without distortion, and requires no complex connection. Just with a single USB cable, you are connected and ready for conferencing.
Unmatched Audio Pick Up and Delivery for Smooth Communication
This solution brings you two devices from Shure’s Audio Ecosystem, four (4x) MXN5W-C Ceiling Speaker and the MXA920 24-inch Ceiling Array Microphone. These two devices, when combined, offer you full-duplex audio collaboration, supplying you with high-pitched, intelligible sounds and directionally voice pick up of room participants. Both Shure devices are to be placed in your drop ceiling environment, helping to reduce clutter.
Portable Display Control for Room Management
The two included touchscreen control features a colour high-capacitive display screen that is 7 inches wide. The Crestron UC-MM30-R tabletop conference device is combined with high-performance speakerphones and omnidirectional microphones. Its control panel makes it easy to manage the Crestron Home operating system to provide a single convenient home office companion. Using the Crestron TS-770-W-S Tabletop Touch Screen, you can schedule meetings. Both devices are capable of performing functions such as browsing the internet, streaming videos and music, and more.
Ultrawide Screen Monitor for Touch Interaction
Get your entire team engaged in meeting collaborations through an ultrawide screen interactive display - the Dell P8624QT 86" 4K Interactive Touch Monitor. This enterprise-class monitor offers true-to-life images with its brilliant 85.6-inch 4K ultra-high-definition large screen. Multiple users can make reference to a specific point during an on-screen presentation, thanks to its 20-point touch capability for making it possible. Also, while participants interact with this intuitive touch screen, it is almost impossible for your palm to mistakenly erase as it comes built with palm rejection. The Dell P8624QT supports USB-C connectivity and comes with built-in dual 20W speakers for intelligible sound production.
Crestron RMC4 4-Series Control System
The Crestron RMC4 is a PoE+ powered device that offers a highly secured performance control processor and interface for monitoring and controlling small audio/video systems, single display devices, lighting and shading, climate control, energy management, security, and many other specialised applications. This enterprise standard comes in a compact and portable design and offers versatile attachments behind display screens and projectors.
What's in the Box?
- Crestron UC-MM30-R Tabletop Conference Device
- Power Adapter
- Crestron RMC4 4-Series Control System
- Crestron TS-770-W-S 7 in. Tabletop Touch Screen
- Shure MXN5W-C Loudspeaker 4x
- Magnetic grille with removable Shure logo
- Flexible conduit clamp
- Cover plate
- Shure MXA920 24" Ceiling Array Microphone
- Strain relief tabs (3)
- Cable ties (8)
- Rubber pad set
- Documentation
- Huddly IQ Camera for Conference Rooms Kit
- Dell P8624QT 86" 4K Interactive Touch Monitor
- 2 Styluses
- Remote Control Holder
- 3 x wire saddles
- 2 stylus nibs, 1 x PC box holder
- SuperSpeed USB Cable
- DisplayPort Cable
- USB-C Cable
- HDMI Cable
- Quick Start Guide
Huddly & Shure Audio/Video Conferencing Solution - Medium Room Specifications
Crestron UC-MM30-R
Communications
Ethernet:
- 10/100 Mbps, auto-switching, auto‑negotiating, auto-discovery, full/half duplex, DHCP, TCP/IP, UDP/IP, CIP, SSL, TLS, SSH, SFTP (SSH File Transfer Protocol), SRTP, IEEE 802.1X, Active Directory® authentication, digest access authentication, password login, Microsoft Intune® client, IEEE 802.3at Type 2 PoE+ compliant
Wi-Fi®:
- Dual-band 802.11a/b/g/n/ac (2.4 GHz and 5 GHz)
Touch Screen
- Display Type: TFT active matrix colour LCD
- Size: 7 in. (178 mm) diagonal
- Touch Screen: Capacitive, multi‑touch capable
- Resolution: 1200 x 800 pixels
- UI: Crestron Home™ OS
Buttons and Indicators
- Mic Mute Symbol: (4) Capacitive buttons with bi‑colour LEDs, toggles between mute and unmute; Green indicates unmute, red indicates mute
- Light Bar: Bi-colour LED responds to mute and unmute; Green indicates unmute, red indicates mute
Audio
- Acoustic Echo Cancellation: Automatic gain control, dynamic noise reduction, acoustic echo cancellation, full‑duplex IEEE 1329 Type 1 compliant
Speaker
- Full range speaker
- Amplifier Power: 7 W (rated power)
- Output Volume: 83 ±3 dBA @1m 1 kHz
- Frequency Response: 100 Hz - 20 kHz
Microphones
- (4) Built-in omnidirectional, digital MEMS microphones with 360° audio pickup
- Maximum pickup range: 10 ft (3 m) typical
Occupancy Sensor
- Detection Range: Approx. 10 ft (3 m) PIR range in front of touch screen
- Coverage Pattern: ±45° horizontally
Connectors
LAN:
- (1) 8‑pin RJ‑45 connector, female;
- 100BASE-TX/1000BASE-T Ethernet port;
- PoE+ PD (powered device) port;
- PoE+ injector and cables included
USB
- (1) Micro-USB Type B connector, female;
- USB 2.0 device port;
- 5.8 ft (1.8 m) USB micro-B to A cable included
Security Port
- Kensington Security Slot™ port
Power
- Power over EthernetIEEE 802.3af Class 3 and 802.3at Class 4 PoE+ powered device;
- PoE+ injector included
Dimensions
- Height: 3.02 in. (77 mm)
- Width: 7.17 in. (182 mm)
- Depth: 9.61 in. (244 mm)
- Weight: 2.1 lb (0.96 kg)
Compliance
- Regulatory Model: M201928001
- FCC Part 15 Class B, IC , CE, UL® Listed
Crestron RMC4 4-Series Control System
Control Engine
- Crestron® 4-Series™; real-time, preemptive multi-threaded/multitasking kernel; Transaction-Safe Extended FAT file system; supports up to 10 simultaneously running programmes (licence required)
Communications
- Ethernet: 100 Mbps, auto‑switching, auto‑negotiating, auto‑discovery, full/half duplex, industry-standard TCP/IP stack, UDP/IP, CIP, DHCP, SSL, TLS, SSH, SFTP (SSH File Transfer Protocol), FIPS 140-2 compliant encryption, IEEE 802.1xX, SNMP, BACnet and IP3, IPv4 or IPv6, Active Directory® service authentication, HTTPS web server, HTTPS web browser setup and XiO Cloud® client, SMTP email client
- Cresnet: Cresnet master mode
- USB: Supports computer console and USB mass storage class devices via the front panel USB OTG (On‑the‑Go) device port
- RS-232/422/485 For 2-way device control and monitoring, supports RS-232, RS-422, or RS-485 up to 115.2k baud with hardware and software handshaking
- IR/Serial: Supports 1-way device control via infrared up to 1.2 MHz or serial TTL/RS-232 (0–5 V) up to 115.2k baud
Memory
- SDRAM: 1 GB
- Flash: 8 GB
- External Storage: Supports USB mass storage devices up to 1 TB
Connectors
USB-OTG
- (1) USB Type Micro-AB female;
- USB OTG port for computer console and USB mass storage devices
LAN PoE
- (1) 8-pin RJ-45 connector, female;
- 100BASE-T Ethernet port;
- PoE (Power over Ethernet) PD (Powered Device) port
NET
- (1) 3-pin 3.5 mm detachable terminal block;
- Cresnet master port;
- Provides data only (no power)
DIGITAL IN 1–2
- (1) 3-pin 3.5 mm detachable terminal block;
- Comprises (2) digital inputs (referenced to GND);
- Voltage Range: Rated for 0–24 VDC;
- Input Impedance: 2.2k Ω pulled up to 5 V;
- Logic Threshold: >2.0 V low/0 and <1.1 V high/1
RELAY 1–2
- (1) 4-pin 3.5 mm detachable terminal block;
- Comprises (2) normally open, isolated relays;
- Rated 1 A, 30 VAC/VDC;
- MOV arc suppression across contacts
IR 1–2
- (1) 4-pin 3.5 mm detachable terminal block;
- Comprises (2) IR output ports;
- IR output up to 1.2 MHz;
- 1-way serial TTL/RS-232 (0–5 V) up to 115.2k baud;
- IRP2 IR emitters sold separately
COM
- (1) 5-pin 3.5 mm detachable terminal block;
- Bidirectional RS‑232/422/485 port;
- Up to 115.2k baud;
- Hardware and software handshaking support
G
- (1) 6-32 screw;
- Chassis ground lug
Controls and Indicators
- PWR: (1) Bicolour green/amber LED, indicates operating power is present; Amber indicates that the device is booting and is not yet ready to operate; Green indicates that the device is ready to operate
- NET: (1) Amber LED, indicates communication with Cresnet devices
- MSG: (1) Red LED, indicates processor has generated an error message
- HW-R: (1) Recessed push button, initiates hardware reset
- SW-R: (1) Recessed push button, initiates software reset
LAN PoE
- (1) Green and (1) Amber LEDs
- Green LED indicates Ethernet link status and connection speed
- Amber LED indicates Ethernet activity
Power
- Power over Ethernet: IEEE 802.3at Type 1 (802.3af compatible) Class 0 (12.95 W) PoE Powered Device
- Power Consumption: 6.5 W
NOTE: The RMC4 does not use or supply any Cresnet power.
Environmental
- Temperature: 32 to 104 °F (0 to 40 °C)
- Humidity: 10% to 90% RH (non condensing)
- Heat Dissipation: 22 BTU/hr
Construction
- Enclosure: IFE micro form factor, black and blue plastic
Mounting:
- Freestanding, stackable, surface mount, or 35 mm DIN EN 60715 rail mount;
- Occupies 8 DIN module spaces (144 mm);
- Surface/DIN rail mounting bracket included, optional rack mount and pole mount kits sold separately
Dimensions
- Height: 1.35 in (35 mm); 1.77 in (45 mm) with bracket
- Width: 5.04 in (128 mm); 5.36 in (137 mm) with bracket
- Depth: 2.86 in (73 mm)
Weight: 6.4 oz (180 g)
Compliance
Regulatory Model: RMC4;
- UL® Listed for US & Canada, CE, IC, FCC Part 15 Class B digital device
Crestron TS-770-W-S 7 in.
Touch Screen Display:
- Display Type: TFT active matrix colour LCD
- Size: 7 in. (178 mm) diagonal
- Aspect Ratio: 16:10 WXGA
- Resolution: 1280 x 800 pixels
- Brightness: 350 nits (cd/m²)
- Contrast: 850:1
- Colour Depth: 24-bit, 16.7M colours
- Illumination: Edge Lit LED with auto brightness control
- Viewing Angle: ±80° horizontal, ±80° vertical
- Touch Screen: Projected capacitive, 5-point multitouch capable
Buttons:
- Hard Keys: (6) Virtual buttons in the collapsible universal toolbar, per‑button show/hide, preconfigured with icons for Power, Home, Lights, Up, Down, and MMicrophone; optional custom programming via control system for additional functions
- Reset: (1) Pin hole on the bottom for hardware reset
Graphics Engine:
- Crestron HTML5 and Smart Graphics® software technology, multi language web browser1, multilingual on screen keyboard, screensaver, single scalable streaming video window, native room scheduling applications, native Sonos® app, native Zoom Rooms app7, native Crestron Home® OS app, setup and diagnostics via web browser, cloud, or onscreen UI
Room Scheduling Support:
- Crestron Scheduling App: Crestron Fusion® software, Microsoft Exchange Server® and Office 365® software, Google Calendar™ and G Suite™ software, CollegeNET® 25Live® software, and Ad Astra software (IBM® Notes® software is also supported through Crestron Fusion on-premises server only)4
- Third-Party Apps: Includes support for various third-party scheduling applications.
Memory:
- RAM: 2 GB LPDDR3
- Storage: Firmware/Application: 16 GB eMMC pSLC
- Maximum Project Size: 600 MB
Wired Communications:
- Ethernet: 100 Mbps, auto-switching, auto-negotiating, auto-discovery, full/half duplex, TCP/IP, UDP/IP, CIP, DHCP, SSL, TLS, SSH, SFTP (SSH File Transfer Protocol), IEEE 802.1X, SNMP, IPv4 or IPv6, Active Directory® service authentication, HTTPS web browser setup, XiO Cloud® client, IEEE 802.3at compliant
- USB: USB 2.0 host for room scheduling accessories
Wireless Communications:
- Transceiver: IEEE 802.11a/b/g/n/ac Wi-Fi (2.4 or 5 GHz 2-way RF), static IP or dynamic IP via DHCP
- Security: 64 and 128-bit WEP, WPA and WPA2-PSK with TKIP and AES
- Range: Up to 50 ft (15 m), subject to site-specific conditions
- Bluetooth® Hardware: Crestron Bluetooth beacon
Streaming Decoder:
- Video Formats: H.265, H.264 (MPEG‑4 part 10 AVC, MJPEG)
- Audio Formats: AAC stereo
- Bitrates: Up to 25 Mbps (20 Mbps maximum recommended)
- Input Resolutions: Up to 1920x1080 at 30 fps
- Protocol: RTSP
Audio:
- Features: Built-in microphone and speakers, Rava® SIP Intercom, voice recognition
- Audio Feedback Formats: MP3
Connectors:
- LAN PoE: (1) 8-pin RJ-45 connector, female, with 2 LED indicators; 100BASE-TX Ethernet port; PoE+ PD port; Green and yellow LEDs indicate Ethernet port status
- USB: (1) USB Type-A connector, female; USB 2.0 host port
Power:
- PoE (Power over Ethernet), IEEE 802.3at Type 2 compliant PoE+ PD (Powered Device);
- Requests 15 W from an 802.3at Type 2 PSE with LLDP advanced power management;
- Requests 30 W (PoE+ Class 4) from an 802.3at Type 2 PSE without LLDP;
- Requests 15.4 W (PoE Class 0) from an 802.3af (or 802.3at Type 1) PSE
Weight:
- 1.33 lb (605 g).
Shure MXN5W-C
- Connector Type: RJ45
- Power Requirements: Power over Ethernet (PoE) Class 0 or PoE Plus Class 4
- Power Consumption:
- Power over Ethernet (PoE): 12 W maximum (11 W typical)
- PoE Plus: 24 W maximum (23 W typical)
- Weight: 6.5 lbs (2.95 kg)
- Product Dimensions: H x W x D: 12 x 12 x 4 in. (304.8 x 304.8 x 101.6 mm)
- Control Software: Shure Designer
- Plenum Rating: UL 2043 (Suitable for Air Handling Spaces)
- Operating Temperature Range:−6.7°C (20°F) to 40°C (104°F)
- Storage Temperature Range:−29°C (-20°F) to 74°C (165°F)
- Frequency Response (-3 dB): 120 Hz to 20 kHz
- Maximum Output Level
At 1 metre
- Power over Ethernet (PoE): 92 dB SPL
- PoE Plus: 98 dB SPL
- Coverage Angle
- Average of 1-octave band centred on 4 kHz: 94°
- Digital Signal Processing
- Delay, Limiter, Signal Generator, Equaliser (4-band Parametric)
Latency
Not including Dante latency
- 1.5 ms
Shure MXA920
Audio
- Acoustic Echo Cancellation Tail Length: Up to 250 ms
- Frequency Response: 125 Hz to 20,000 Hz
- Bit Depth: 24
- Dynamic Range: 77.5 dB
- Self Noise: 18.24 dB SPLA
- Sampling Rate: 48 kHz
- Sensitivity at 1 kHz: −1.74 dBFS/Pa
- Maximum SPL Relative to 0 dBFS overload: 95.74 dBSPL
- Signal-to-Noise Ratio Ref. 94 dBSPL at 1 kHz: 75.76 dB A Weighted
- Latency (Does not include Dante latency)
- Direct outputs (Automatic coverage off): 15.9 ms
- Automix output (Includes IntelliMix processing): 26.6 ms
- Digital Signal Processing: Automatic mixing, acoustic echo cancellation (AEC), noise reduction, automatic gain control, compressor, delay, equaliser (4 band parametric), mute, gain (140 dB range)
Networking
- Connector Type: RJ45
- Cable Requirements: Cat5e or higher (shielded cable recommended)
General
- Coverage Type: Automatic or steerable
- Dust Protection: IEC 60529 IP5X Dust Protected
- Plenum Rating: UL2043 (Suitable for Air Handling Spaces)
- Power Consumption: 10.1 W maximum
- Power Requirements: Power over Ethernet (PoE), Class 0
- Control Software: Designer or web application
- Storage Temperature Range: −29°C (−20°F) to 74°C (165°F)
- Operating Temperature Range: −6.7°C (20°F) to 40°C (104°F)
Physical
- Weight: MXA920-S: 11.8 lbs (5.4 kg)
- Height: 2.15 in. (54.69 mm)
- Microphone flange: 0.41 in. (10.5 mm)
- Edge to edge: 23.77 in. (603.8 mm)
Huddly IQ Camera for Conference Rooms
- 1080p Full HD @ 30 fps
- 16:9 aspect ratio output
- 12 Megapixels 1/2.3” CMOS sensor
- 720p HD @ 30 fps
- UVC 1.1 plug-and-play compatible
Optics
- Ultrawide angle glass optics
- Diagonal field of view 150 ̊
- Vertical field of view 90 ̊
- Horizontal field of view 120 ̊
- f/2.8 aperture
Connectivity
- USB Type-C connector
- Power requirement 5V 900mA
- SuperSpeed USB 3
Hardware
- Aluminium unibody construction
- 5-element beamforming microphone array (optional)
- High-performance video processing engine
- Embedded mounting hinge
- Neural compute engine
- Camera tripod mount
Packaging Dimensions
- L: 80 mm x W: 52 mm x H: 50 mm
Dell P8624QT 86" 4K Interactive Touch Monitor
General:
- Product Type: LED-backlit LCD flat panel display
- Diagonal Class: 86"
- Diagonal Size: 85.6"
- Commercial Use: Yes - interactive
- Combined With: Touch screen (multi-touch)
- Power Consumption Operational: 430 Watt
- Power Consumption (On mode): 170 W
- TV Tuner: No tuner
- TV Tuner Presence: No
- Video Interface: HDMI
- HDMI Ports Qty: 4 ports
- PC Interface: DisplayPort
- Picture Enhancements: 72% Colour Gamut NTSC
- Dimensions: Without stand
- Width: 78.06 in
- Depth: 3.26 in
- Height: 45.54 in
- Weight: 191.80 lb
Display:
- LCD Display Technology: IPS
- Resolution: 3840 x 2160
- Display Format: 4K UHD (2160p)
- Image Aspect Ratio: 16:9
- Brightness: 350 cd/m²
- Viewing Angle: 178°
- Viewing Angle (Vertical): 178°
- Touchpoints Qty: 20
- Response Time: 8 ms
- Pixel Pitch: 0.4935 mm
- Colour Support: 1.07 billion colours
- Frame Rate & Enhancement Technology: 60 Hz Refresh Rate
- LCD Backlight Technology: LED backlight
- Coating: Anti-glare, 9H Hard
- Image Contrast Ratio: 1200:1
- Dynamic Contrast Ratio: 1200:1
- Additional Features: Security lock slot (cable lock sold separately); built-in USB hub
Stands & Mounts
- Flat Panel Mount Interface: 600 x 400 mm
- VESA Compatibility: Yes
Media Player
- USB Port: Yes
Remote Control
- Battery Form Factor: AAA type
- Battery Included: Yes
- Battery Included Qty: 2
- Battery Required Qty: 2
Audio System
- Speaker System: 2 speakers
- Output Power / Total: 40 Watt
- Speakers: 2 - 20 Watt
Connections
Connector Type:
- 4 x USB 3.1 downstream
- 3 x USB 3.1 upstream
- USB
- DisplayPort
- 4 x HDMI
- Audio line-out
- RS-232
- LAN
Miscellaneous:
- Security Slot Type: Kensington security slot
- Compliant Standards: RoHS
| SKU | huddly_shureaudio_microsoft_med |
|---|---|
| Resolution | 1080p |
| Room Size | Medium |
| No. of User(s) | 9-13 |
| Camera Platform Support | Windows, MAC OS |
| Motorised PTZ | No |
| AI Technology | Yes |
| Auto-Tracking | No |
| Plug and Play | Yes |
| Allows for expansion Mic | Yes |
| RightSense Technology | No |
| Conference Set | Conference solution |
| Camera Preset | 2 |
| Camera Zoom | 2x |
| HD Zoom | No |
| Mount Options | Multiple mounting options |
| Certified for Business | No |
| Control | Touch Controller |
| Meeting Solutions | Microsoft Teams® |
| USB Type | USB 2.0 |
| Frame Rate | 30fps |
| Focus Type | Auto Focused |
| Connectivity | Wired |
