Intel NUC 10 Performance NUC10i7FNHN Mini System
- Built with a 10th Gen 3 GHz Intel Core i7-10710U six-core processor
- Features 2 x DDR4-2666 SO-DIMM slots of up to 64GB
- Supports up to three 4K displays simultaneously via HDMI and Thunderbolt 3
- Integrated Intel UHD Graphics that supports up to 4K resolution at 60Hz
- Offers a comprehensive 2 USB-C (DP1 2) and 6 USB ports
- Equipped with 1 x 2.5" Drive Bay and 1 x M.2 2280 slot
- Provides cutting-edge wireless connectivity
- Supports Microsoft Windows 10
- Ultra compact form factor design
Intel NUC 10 Performance NUC10i7FNHN Mini System Description
The Intel NUC 10 Performance NUC10i7FNHN Mini System is a compact yet powerful mini-PC designed for a variety of applications to handle demanding computing tasks with ease, from home offices to digital signage and edge computing. This NUC10i7FNHN is equipped with a 10th Gen 3 GHz Intel Core i7-10710U six-core processor, ensuring robust performance for multitasking and demanding applications. It features 2 x DDR4-2666 SO-DIMM slots of up to 64GB max memory and dual-channel memory support for enhanced performance. It supports up to three 4K displays simultaneously via HDMI and Thunderbolt 3, making it ideal for multitasking and professional workstations. Integrated Intel® UHD Graphics that supports up to 4K resolution at 60Hz across multiple displays. Offering a comprehensive 2 USB-C (DP1 2) and 6 USB ports, the NUC10i7FNHN is equipped with a robust port selection that ensures ample connectivity for peripherals, external drives, and more.
Equipped with 1 x 2.5" Drive Bay and 1 x M.2 2280 slot, this mini system provides ample storage capabilities for storing data. The Intel NUC 10 Performance provides cutting-edge wireless connectivity via Wi-Fi 6 and Bluetooth v5.2 for enhanced connectivity. It supports Microsoft Windows 10 and allows the installation of your preferred operating system, whether it's various Linux distributions or even a home server OS. The NUC's signature small size allows it to fit virtually anywhere, either on a desk, behind a monitor via the included VESA mount, or discreetly integrated into a home entertainment system or kiosk. This saves valuable space and contributes to a clean setup.
Powerful 10th Gen Intel Core i7 Processor
Built with an Intel Core i7-10710U processor, a 6-core, 12-thread CPU that can turbo boost up to 4.70 GHz, it can handle demanding multitasking, content creation such as video editing, music mixing, productivity applications, and even light casual gaming. Its 4.7 GHz turbo frequency delivers strong performance for demanding tasks.
Customisable Barebones Kit
The Intel NUC 10 comes as a barebones unit, allowing you to choose and install your own DDR4-2666MHz SO-DIMM RAM, which supports up to a generous 64GB across two slots. This allows for tailored performance based on your workload. It offers both an M.2 slot that supports NVMe PCIe x4 SSDs for blistering fast boot and application loads. Its 2.5-inch drive bay for SATA SSDs or traditional HDDs provides ample capacity for mass storage, which balances speed and storage volume. The operating system agnostic allows users to install their preferred operating system, whether it's Windows 10/11, various Linux distributions, or even a home server OS.
Rich Connectivity
Offering a comprehensive array of ports, including Thunderbolt 3, HDMI 2.0b, multiple USB 3.1 Gen2 (Type-A and Type-C), USB 2.0, Gigabit Ethernet, and an SDXC card slot, the NUC 10 ensures wide peripheral compatibility. Its robust port selection and support for three displays with 4K high-resolution make it a versatile choice for home users, small businesses, digital signage, and embedded applications where space is at a premium but performance cannot be compromised. Thunderbolt 3 Port is a highly versatile USB-C port that offers blazing-fast data transfer of up to 40 Gbps, supports external graphics cards (eGPUs), and allows for daisy-chaining multiple devices. Several 10 Gbps USB-A and USB-C ports, including a front-facing fast-charging USB-C, ensure ample connectivity for peripherals, external drives, and more. The HDMI 2.0b port is for connecting to monitors or TVs, supporting 4K resolution at 60Hz.
Optimised for Performance and Efficiency
Integrated Intel UHD Graphics are capable of smooth 4K video playback, casual gaming, and handling typical productivity tasks and content creation applications. The NC 10 is designed to be energy-efficient, making it suitable for always-on applications or environments where power consumption is a concern. It includes a VESA mounting kit, allowing you to securely attach it to the back of a VESA-compatible monitor or TV, further decluttering your workspace.
What's in the Box?
- Intel NUC 10 Performance NUC10i7FNHN Mini System
- VESA Mounting Bracket
- Screws
- Power Adapter
- Documentation
Intel NUC 10 Performance NUC10i7FNHN Mini System Technical Specs
Processor
- Intel® Core™ i7-10710U processor (3 GHz with 4.7 GHz Turbo, Six Core, Hyper-Threading,12 MB Smart Cache, 25W TDP)
Storage Capabilities
- One M.2 socket supporting 22x42 or 22x80 M.2 SSDs, SATA or PCIe, 2TB Max.
- Intel® Optane™ Memory ready
- One SATA 3 port for connection to 2.5" HDD or SSD up to 9.5mm thick (4TB SSD or 2TB HDD Max)
Audio
- Up to 7.1 surround via HDMI
- Front headset jack
- Quad-array far-field beam-forming microphones in the front panel
Hardware Management Features
- Voltage and temperature sensing
- ACPI-compliant power management control
- Processor fan speed control
- Fan sensor inputs are used to monitor fan activity
Graphics
- Intel® UHD Graphics
- One HDMI 2.0a port
- USB Type-C port with DisplayPort 1.2
- Max 3x 4K @ 60Hz displays
Peripheral Connectivity
- Intel® Gigabit LAN i219-V
- Three USB 3.1 Gen2 Type-A ports (two back; one front)
- Two USB 3.1 Gen2 Type-C ports (one back, one front with charging)
- Two additional Hi-Speed USB 2.0 ports via internal header
- Intel® Wi-Fi 6 AX200 (802.11ax), 2x2, up to 2.4 Gbps
- Bluetooth 5
- Thunderbolt 3 on USB Type-C port
- Consumer infrared receiver on the front
Baseboard Power Requirements
- 19V, 120W AC-DC power adapter with detachable power cord.
- 12- 19V DC input range
- International cords available
Mechanical Chassis Size
- 4.6” x 4.4” x 2.0”
- 117 x 112 x 51 mm
System Memory
- Two DDR4-2666 SO-DIMM sockets, 64GB Max, 1.2V
System Bios
- 64 Mb Flash EEPROM with Intel® Platform Innovation Framework for EFI Plug and Play
- Advanced configuration and power interface V3.0b, SMBIOS2.5
- Intel® Visual BIOS
- Intel® Express BIOS update support
Front Panel Header
- Reset, HDD LED, Power LEDs, power on/off
Expansion Capabilities
- Two USB 2.0 ports on two 1x4 headers
- 2.5in drive bay for SATA drive
- Functional or decorative lid support
- HDMI CEC header
Certifications and Regulations
Product Safety Regulations and Standards
- IEC 60950-1
- UL 60950-1
- EN 60950-1
- CAN/CSA-C22.2 No. 60950-1
Environment Operating Temp
- 0° C to +50° C
- Non-condensing Humidity
Storage Temperature
- -40° C to +60° C
EMC/RF Regulations and Standards (Class B)
- CISPR 52
- FCC CFR Title 47, Chapter I, Part 15, Subparts B, C, E
- ICES-005
- EN 55052
- EN 55024
- ETSI EN 500 528
- ETSI EN 501 489-1
- ETSI EN 501 489-17
- ETSI EN 501 895
- EN 62511
- AS/NZS 2772.2
- AS/NZS 4268
- VCCI V-2, V-5, V-4
- KN-52
- KN-24
- CNS 15458
Environmental Regulations
- RoHS Directive 2011/65/EU
- WEEE Directive 2012/19/EU
- China RoHS
More Information
| Delivery Option | Same/Next Day Delivery |
|---|---|
| SKU | NUC10i7FNHN |
| Weight | 3.000000 |
| Brand | Intel |
| Form Factor | SFF/Mini Desktop Computer |
| Processor | Intel Core i7 6-Core (10th Gen) |
| No. of CPUs | 6-cores |
| RAM Type | DDR4 |
| Storage Type | Hybrid Drive |
| Graphics Type | Integrated |
| Ports | 3.5mm headphone Jack, Ethernet, DisplayPort, HDMI, USB 3.0 |
| Operating System | OS Not Included |
