Intel NUC 8 Mainstream Kit Mini PC - Core i3 8th Gen, Tall, Add't Components Needed
- 8th generation Intel Core i3-8109U processor
- Up to 32 GB Intel Optane memory ready
- M.2 slot with flexible support for a 42 or 80 mm M.2 SSD
- Intel Dual Band Wireless-AC 9560 and Bluetooth 5.0
- HDMI 2.0a display port supporting 8-channel audio (7.1 surround sound)
- Thunderbolt 3 USB Type-C port providing DisplayPort 1.2 or USB 3.1 gen 2
- Minimal fan noise aiding a quieter experience
Intel NUC Core i3 8th Gen Description
The Intel NUC8i3BEH is a compact PC that offers outstanding features and can be customised to have the functionality and features of a desktop PC while still fitting into any space. Whether you are working on word processing, presentations, or streaming movies, it is readily available and reliable. There is space for a 2.5" HDD/SSD and a dual slot for DDR4 SO-DIMM that is compatible with Intel Optane memory and when coupled together, performance is greatly improved. With improved cooling, fan noise is minimal, meaning a quieter experience irrespective of where the Intel NUC is positioned.
Reliable Features
The chassis of the Intel NUC PC is a connectivity powerhouse, featuring Thunderbolt 3 connectors that can transfer data at up to 40 GB/s, four USB 3.1 ports, and two more USB ports through internal 1x4 headers and M.2 22x42/80 slot for PCIe NVMe or SATA SSD can fit as well. An HDMI 2.0a port and a DisplayPort 1.2 port through USB-C allow the Intel NUC compact PC to accommodate three 4K Ultra HD displays simultaneously without sacrificing image quality.
What’s In The Box?
- Intel NUC 8 Mainstream Kit Mini PC - Core i3 8th Gen
- 19V Power Adapter
- VESA Mounting Plate
- Manual
Intel NUC Mini PC Specs
Processor
- Intel® Core™ i3-8109U processor (3.0 GHz - 3.6 GHz, Dual Core, 4 MB Cache, 28W TDP)
Graphics
- HDMI 2.0a port with 4K at 60 Hz
- Iris® Plus Graphics 655
- USB Type-C port with DisplayPort 1.2
System Memory
- Two DDR4 SO-DIMM sockets (up to 32 GB, 2400 MHz), 1.2V
Intel Optane Memory
- Room for up to 32 GB in an M.2 slot
Peripheral Connectivity
- Intel® Gigabit LAN
- Four USB 3.1 ports (two back panel ports and two front ports including one charging port)
- Thunderbolt™ 3 with data transfer up to 40 Gbps
- Two additional USB 2.0 ports via internal header
- Dual Mode Bluetooth 5.0
- Intel® Dual Band Wireless-AC 9560 (802.11ac), 2x2, up to 1.73 Gbps
Storage Capabilities
- Micro SDXC slot with UHS-I support on the side
- One SATA3 port for connection to 2.5" HDD or SSD (up to 9.5 mm thickness)
- One M.2 connector supporting 22x42 or 22x80 M.2 SSD
System Bios
- Advanced configuration and power interfaceV3.0b, SMBIOS2.5
- 64 Mb Flash EEPROM with Intel® Platform Innovation Framework for EFI Plug and Play
- Intel Express BIOS update support
- Intel Visual BIOS
Hardware Management Features
- Processor fan speed control
- Fan sensor inputs used to monitor fan activity
- Voltage and temperature sensing
- ACPI-compliant power management control
Expansion Capabilities
- One Consumer Electronics Control header
- Two Internal USB 2.0 ports via two 1x4 headers (for replaceable lid support)
Audio
- Up to 7.1 surround audio via HDMI
- Headphone/microphone jack on the front panel
- Dual-array microphones on the front panel
Front Panel Header
- Reset, HDD LED, Power LEDs, power on/off
Mechanical Chassis Size
- 4.60" x 4.40" x 2.01"
- 117 mm x 112 mm x 51 mm
Baseboard Power Requirements
- 19V, 90W power brick
Product Safety Regulations and Standards
- IEC 60950-1
- UL 60950-1
- EN 60950-1
- CAN/CSA-C22.2 No. 60950-1
EMC/RF Regulations and Standards (Class B)
- CISPR 32
- FCC CFR Title 47, Chapter I, Part 15, Subparts B, C, E
- ICES-003
- EN 55032
- EN 55024
- ETSI EN 300 328
- ETSI EN 301 489-1
- ETSI EN 301 489-17
- ETSI EN 301 893
- EN 62311
- AS/NZS 2772.2
- AS/NZS 4268
- VCCI V-2, V-3, V-4
- KN-32
- KN-24
- CNS 13438
Environmental Regulations
- WEEE Directive 2012/19/EU
- RoHS Directive 2011/65/EU
- China RoHS - Management Methods for Restricted Use of Hazardous Substances in Electrical and Electronic Products
More Information
| Delivery Option | 15-20 Working Days |
|---|---|
| SKU | NUC8i3BEH |
| Brand | Intel |
| Form Factor | SFF/Mini Desktop Computer |
| Processor | Intel Core i3 Dual-Core (8th Gen) |
| RAM Type | DDR4 |
| Storage Capacity (HDD) | No Drive Installed |
| Storage Capacity (SSD) | No Drive Installed |
| Graphics Type | Integrated |
| Optical Drive | None Available |
| Ports | 3.5mm headphone Jack, DisplayPort, HDMI, RJ45, Thunderbolt 3, USB 3.1 (Gen 2) Type-C Female |
| Flash Media Expansion Slots | SD |
| Operating System | Windows 10 Home |
