- Gooseneck microphone with Sennheiser super-cardioid capsule
- Features DSP limiter
- Comes with digital delegate conferencing unit
- Built in a modern industrial design
- Features hidden cable connections
- Offers effective twin loudspeakers
- Provides convenient cabling via RJ45 sockets
- Strain relief available for fixed installations
- Features microphone Key button/LED light indicator
- Measures 15” gooseneck length
Sennheiser ADN D1 Gooseneck Microphone Description
Sennheiser ADN D1 comes with a Digital Delegate Conferencing Unit, which is part of Sennheiser's Audio Distribution Network conferencing system. The ADN D1 microphone offers high speech intelligibility in a modern industrial design. The gooseneck microphone features a DSP limiter that is used for speech compression as well as setting limits to safeguard any professional audio amplifier. Equipped with a super-cardioid capsule that attenuates unwanted noise efficiently, the ADN D1 microphone helps deliver quality audio performance without noise interference. A twin-loudspeaker system guarantees a homogenous sound level in the meeting room.
The microphone operates in either direct access mode, wherein any delegate may speak at any time, or in "request" mode wherein you must add a name to a list of delegates waiting to speak, and wait to be granted permission by the chairperson unit. This functionality can be carried out with the microphone key button featured in the ADN D1 gooseneck microphone. The device connects to the ADN D1 central unit via a Cat 5 cable and functions as a delegate's microphone and playback speaker. Hidden cable connections can be optionally secured with strain reliefs for fixed installations. The ADN D1 measures 15” gooseneck length.
Quality Audio Delivery
Enjoy quality audio delivery with the Sennheiser ADN D1 gooseneck microphone. The ADN D1 microphone delivers quality audio with the featured two loudspeakers and a super-cardioid capsule that helps reduce unwanted ambient noise efficiently while capturing sound in front of the microphone without noise interference.
LED Indicator
The Sennheiser ADN D1 gooseneck microphone features an LED indicator that switches on (red light) when the microphone is active. The microphone button on the base of the unit and the LED signal indicator ring below the capsule will glow red and switch off when the microphone is inactive.
DSP Limiter
The Sennheiser ADN D1 features a DSP limiter that allows you to set level threshold values, ensuring that the signal level cannot exceed a specific range. Never worry about the microphone exceeding its operation capacity thanks to the Digital Signal Processing limiter that prevents clipping. A limiter catches the loudest peaks of an audio source and applies brick wall compression that prevents it from exceeding the clipping point of 70 dB(A).
What's In The Box?
- Sennheiser ADN D1 Gooseneck Microphone
- Quick Guide
Sennheiser ADN D1 Specifications
Dimensions (w/o gooseneck)
- 185x63x140mm (WxHxD)
Weight
- Approx.700g
Supply voltage
- 35V....52.8
Power consumption
- 2W (w/o reproduction via loudspeakers)
Temperature range operation
Operation
- +10°C to 40°
Storage
- 25°C to 70°C
Relative humidity
Operation
- 10 % to 80 %
Storage
- 10 % to 90 %
Headphone Socket
- 3.5 mm stereo jack socket
Output level at headphone socket
- 50mW/16 Ω
DHT (At 1 KHz)
- 0,03 at 50 mW/16 Ω
Loudspeaker
Frequency response
- 100Hz to 14.5 KHz
Signal-to-noise ratio
- 70dB(A)
Microphone
Pick up pattern
- Super-cardioid
Frequency response
- 190 Hz to 14.5 KHz
More Information
| Delivery Option | 15-20 Working Days |
|---|---|
| SKU | ADN D1 |
| Accessories Brand | Sennheiser |
| Accessories Type | Microphone |
| Connection Type | Wired |
| Mount Type | Desk Mount |
| Type | Ethernet |
| Condition | New |
