Zebra ZT231 Label Printer - 4, 203 dpi, Direct Thermal, Tear, USB, Serial, Ethernet, BTLE
- Constructed with a metal frame and metal enclosures
- Suitable for light industrial environments
- Features a 4.3 inches colour touchscreen
- Offers a maximum print width of 4-inch – 203 dpi, and 4-inch – 300 dpi
- Supports direct-thermal or thermal-transfer printing method
- Built with a Bi-fold media door for easy opening and a large clear window to easily view ribbon
- Prints crisp text and barcodes at resolution of 203 dpi, or use an optional 300 dpi
- Supports USB, Serial, 10/100 Ethernet, Bluetooth Low Energy 5.1, USB Host
- Bluetooth Low Energy (BTLE) technology for enhanced location precision
ZT231 Label Printer Description
A harsh and demanding environment needs a powerful printer that can withstand broad functionality. The Zebra’s ZT231 label printer is the right solution for light industries with large numbers of activities. This printer offers outstanding functionality and characteristics while maintaining rigorous standards of printing and reliability. It can be used for various industrial needs, such as printing asset labels and shipping, laboratory samples or compliance labelling.
Additionally, it offers a quick impression, high-resolution print quality, and a 4.3-inch colour touch screen that makes it simple to monitor and manage scanning activities. It also provides extra features like RFID, wireless connectivity, and media control capabilities. The ZT231 label printer is built with USB, Serial, 10/100 Ethernet port, and USB Host.
BUILT TO PERFORM. ENGINEERED TO ENDURE
Don’t Compromise on Quality
The ZT231 printer is built with a durable metal frame which makes it ideal for light industrial environments. Take your label throughput to the next-level with the industry-leading printer with print speeds up to 12 ips at 203 dpi. It comes with an optional resolution which prints crisp text and barcodes at 300 dpi resolution.
Simple Operation with Smart Features
Zebra introduces an easy to use 4.3 inches colour touchscreen to the ZT231 printer. This screen helps to reduce training time by making it easier to manage the printer’s operation. You can now access wizards and helpful how-to videos and make changes with the touch of a finger or gloved hand. Use the ZT231's backwards compatibility and Printer Emulations to seamlessly replace other brands on your network without changing label formats or rewriting code.
Small Footprint, Big Access
This version of Zebra’s industrial printer is easy to deploy into workspaces. It is designed to perfectly save enough space with its compact design and bi-fold door that reduces the height needed to open your printer. With an easy layout and colour-coded cues, media loading will be hassle-free. More media flexibility is provided by adjustable sensors, and a large ribbon roll capacity enables less frequent media changes.
Connect Your Way
On the ZT231 printer, you have broad options to connect a variety of standard connectivities, including USB, Serial, Ethernet and USB Host. It comes with a Print Touch tag (NFC) which makes it possible to tap, pair and print with compatible mobile devices, add a second Ethernet port, 802.11ac or an Applicator port.
Get RFID Without Complication
It is incorporated with UHF RFID printing and encoding for greater visibility and tracking. Zebra's adaptive encoding technology, which does away with complicated positioning standards, gives you more media freedom and straightforward RFID calibration.
What's in the Box?
- Zebra ZT231T 203 dpi Thermal Transfer Industrial Printer with Ethernet, USB, Serial, BLE, Tear Bar
- Power Cord
- Cleaning Pen
Zebra ZT231 Specifications
Standard Features
- Print methods: direct-thermal or thermal-transfer
- Construction: metal frame and metal enclosures
- Bi-fold media door with large clear window
- Side-loading supplies path for simplified media and ribbon loading
- Thin film printhead with E3™ Element Energy™ Equaliser for superior print quality
- Three-colour LEDs for quick printer status
- 4.3” colour resistive touch screen with intuitive menu for quick operation and settings
- Communications: USB 2.0, RS-232 Serial port, 10/100 Ethernet, and USB Host
- ENERGY STAR® certified
- Bluetooth Low Energy (BTLE) technology for enhanced location precision
- Real-Time Clock (RTC)
Physical Characteristics
Dimensions
- ZT231 Closed: 17 in. L x 9.5 in. W x 11 in. H / 432 mm L x 241 mm W x 279 mm H
- ZT231 with Liner Takeup Unit: 17 in. L x 9.5 in. W x 12.75 in. H / 432 mm L x 241 mm W x 324 mm H
Weight
ZT231: 20 lbs./9.1 kg
Resolution
- 203 dpi/8 dots per mm
- 300 dpi/12 dots per mm (optional)
Memory
- 256 MB SDRAM memory
- 256 MB on-board linear Flash memory
Maximum Print Width
- 4.09 in./104 mm
Maximum Print Speed
- 12 ips (203 dpi)
- 8 ips (300 dpi)
Media Sensors
- Moveable transmissive and reflective sensors
Maximum Print Length
- 203 dpi: 157 in/3988 mm
- 300 dpi: 73in/1854 mm
Media Characteristics
Minimum Label and Liner Length
- Tear mode: 0.7 in/18 mm
- Cutter mode: 1 in/25 mm
- Peel mode: 0.5 in/13 mm
Media Width
- 0.75 in./19.4 mm to 4.50 in./114 mm
Media Roll Size
- 8.0 in./203 mm O.D. on a 3.0 in./76 mm I.D. core
- 6.0 in./152 mm O.D. on a 1.0 in./25 mm I.D. core
Media Thickness
- 0.003 in./0.076 mm to 0.010 in./0.25 mm
Media Types
- Continuous, die-cut, notch, black mark
Ribbon Characteristics (Thermal-transfer option only)
Standard Length: 1,476 ft./450 m
Width: 2 in./51 mm to 4.33 in./110 mm
Core: 1.0 in./25.4 mm
Operating Characteristics
Operating Temp.
- Thermal transfer: 40ºF to 105ºF/5º to 40ºC
- Direct thermal: 32ºF to 105ºF/0º to 40ºC
Storage/Transportation
- Temperature: -40ºF to 140ºF/-40º to 60ºC
- Operating Humidity: 20% to 85% non-condensing
- Storage Humidity: 5% to 85% non-condensing
Electrical
- Universal auto-ranging (PFC-compliant)
- power supply 100-240 VAC; 50-60 Hz
ENERGY STAR certified
- Agency Approvals: IEC 62368-1, EN55022 Class B, EN55024, EN55035, EN61000-3-2, EN 61000-3-3, FCC Class B, ICES-003, FCC 15.209; 15.247(d), IC RSS 247, EN 300 328, EN 301 893, EN 62311, cTUVus, CE Marking, UKCA, VCCI, RCM, S- Mark, CCC, CU EAC, BSMI, KCC, & BIS
More Information
| Delivery Option | 15-20 Working Days |
|---|---|
| SKU | ZT23142-D0E000FZ |
| Brand | Zebra |
| Interface | USB, Serial & Ethernet, Bluetooth |
| Print Resolution | 203 dpi |
| Printer Method | Thermal Transfer |
| Printer Type | Light Industrial |
| Maximum Print Width | 4.25" max width |
| Label Printers Type | Desktop Printers |
