Zebra ZT510 (ZT51043-T210000Z) Thermal Transfer Label Printer
- Integrated black-lit multi-line graphics LCD
- Supports thermal transfer and direct thermal print modes
- Built-in keypad for easy operation
- Powered by Cortex A9 800MHz processor
- Delivers 203 dpi high print resolution (8 dots/mm)
- Supports dual media sensors and Real-time Clock (RTC)
- Advanced label/media counters with auto-calibration
- Offers a printing speed of up to 8 inches per second
- Multiple connectivity options via USB 2.0, Ethernet, and optional Bluetooth for easy integration
- Built with rugged construction for industrial environments
- ENERGY STAR certified
Zebra ZT510 (ZT51043-T210000Z) Thermal Transfer Label Printer Description
The Zebra ZT510 is an industrial-grade label printer, a part of Zebra's ZT500 Series, combining robust performance, durability, and easy integration into your business operations. The printer is engineered with a customisable black-lit multi-line graphic LCD day with an intuitive menu for easy operation, enabling simple navigation and access. It supports thermal transfer and direct thermal print modes to handle high volumes of documents, allowing users to choose the most appropriate printing method for their specific application which makes it versatile for various label types and applications.
The ZT510 offers a printing speed of up to 8 inches per second, allowing you to print documents faster to ensure efficiency and productivity in the work environment. It provides a high print resolution of 203 dpi for clear and readable labels. Featuring a high media capacity of up to 8.6 inches in width and a label roll capacity of 8 inches, the ZT510 printer enables long printing runs without frequent reloading. The ZT510 comes with USB 2.0, Ethernet, and optional Bluetooth for easy integration into your existing systems, making it ideal for businesses that require constant connection to compatible devices in the application environment. Built with rugged construction for industrial environments, the ZT510 is designed to meet the rigorous demands of warehouses, manufacturing facilities, and logistics operations, making it a cost-effective labelling solution for businesses. It is ENERGY STAR certified and designed to reduce energy consumption without sacrificing performance.
High Resolution and Print Speed
Designed for businesses looking for an affordable yet durable label printer that delivers high-quality prints, the Zebra ZT510 printer provides a high print resolution of 203 dpi for clear, readable labels with sharp barcodes. It offers a printing speed of up to 8 inches per second, ensuring fast production even in high-demand environments.
Easy-to-Use Control Panel
Engineered with a large graphical display, the ZT510 LCD makes it simple to operate, reducing the training time required for new users. The ZT510 comes with features such as intuitive setup, ease of operation, and compatibility with various media types, making it a great fit for shipping labels, inventory tracking, barcodes, and more.
Rugged Design
Built for industrial environments, the ZT510 printer ensures longevity even in demanding conditions. It is constructed for durability with a steel frame and metal print mechanism, enabling it to handle harsh industrial environments.
Versatile Connectivity
The Zebra ZT510 printer comes with USB 2.0, Ethernet, and optional Bluetooth for easy integration into your existing systems. With these universal connectivity options, you can easily integrate the printer into your workspace, enabling flexible integration.
What's in the Box?
- Zebra ZT510 Thermal Transfer Label Printer
- Power Adapter
- User Manual
Zebra ZT510 Thermal Transfer Label Printer Technical Specs
Standard Features
- Print Methods: Thermal transfer and direct thermal printing
- Construction: Metal frame
- Thin film printhead with E3™ Element Energy™ Equalizer for superior print quality
- Communications: USB, Serial, Gigabit Ethernet, Bluetooth® LE
- Backlit, multi-line display including an intuitive menu, easy-to-use keypad and password protection
Printer Specifications
Resolution
- 203 dpi/8 dots per mm
- 300 dpi/12 dots per mm (optional)
Memory
- 512 MB RAM memory
- 2 GB on-board linear Flash memory
Maximum Print Width
- 4.09"/104 mm
Maximum Print Speed
- 12 ips/305 mm per second
Media Sensors
- Dual media sensors: transmissive and reflective
MaximumContinuous Print Length
- 203 dpi: 150"/3810 mm
- 300 dpi: 100"/2540 mm
Media Characteristics
Media Width
- 0.79"/20 mm to 4.5"/114 mm
Maximum Media Roll Size
- 8.0"/203 mm O.D. on a 3"/76 mm I.D. core
Thickness
- 0.003"/0.076 mm to 0.012"/0.305 mm
Media Types
- Continuous, die-cut, notch, black-mark
Ribbon Characteristics
- Standard Length: 1476'/450 m
- Width: 2.00"/51 mm to 4.33"/110 mm
- Core: 1.0"/25.4 mm I.D.
Operating Characteristics
Environmental Operating Temperature
- Thermal transfer = 40°F to 104°F/5°C to 40°C
- Direct thermal = 32°F to 104°F/0°C to 40°C
Operating Humidity
- 20% to 85% non-condensing
Storage/Transportation Temperature
- -22°F to 140°F/ -30°C to 60°C
Storage Humidity
- 20% to 85% non-condensing
Electrical
- Auto-detectable (PFC Compliant) 90-265 VAC, 47-63Hz, rated at 250 Watts ENERGY STAR qualified
Agency Approvals
- IEC 60950, EN 55022 Class B, EN 55024, EN 61000-3-2, EN 61000-3-3 cTUVus, CE Marking, FCC-B, ICES-003, VCCI, C-Tick, NOM, S-Mark (Arg), CCC, CU, BSMI, KCC, SABS, IN-Metro
Software Tools
- Link-OS Solutions
- Document Design – Quickly design a customized print solution using your business data and Zebra’s intuitive plug-and-print design tools.
- Device Integration – Zebra offers apps and products designed to help you integrate Zebra devices into your existing systems.
- Device Management – Manage your print operations locally and globally with Zebra’s suite of device management tools.
- Developer Tools – Provides you with the tools you need to create your own apps, including documentation, source code, programming languages, templates, and more. Web View
- Connect and control Zebra barcode printers using ZPL II via the printer’s web interface using common web browsers. Alert Printers equipped with ZebraNet print servers will notify you via any email-enabled, wired or wireless device to minimise downtime
Firmware
- ZBI 2.0™ – Optional powerful programming language lets printers run stand-alone applications, connect to peripherals, and much more.ZPL and ZPL II® – Zebra Programming Language provides sophisticated label formatting and printer control, and is compatible with all Zebra printers. XML-enabled Printing – allows XML communications for barcode label printing.
Barcode Symbologies
- Linear Barcodes: Code 11, Code 39, Code 93, Code 128 with subsets A/B/C and UCC Case Codes, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2- or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar, Planet Code 2D Barcodes: Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, TLC 39, MicroPDF, RSS-14 (and composite), Aztec
Fonts and Graphics
- 16 resident expandable ZPL II bitmap and two resident scalable ZPL fonts Asian and other international scalable and smooth bitmapped fonts Unicode™: For multi-language printing Downloadable objects include graphics, scalable and bitmap fonts, label templates and formats. IBM Code Page 850 international character sets are available in the fonts A, B, C, D, E, F, G and 0 through software control Code Page 1250, 1252, 1253, 1254, 1255 Support with font 0. 32 MB user available DRAM 512 MB user available on-board Flash
Options and Accessories
Connectivity
- Two open communication slots to add internal cards for 802.11ac, parallel, and Ethernet. The IPv6 option is available as an external dongle attached to a parallel port Media Handling
- Rewind: Internally rewinds a full roll of printed labels on 3" core, or peels and rewinds liner
- Cutter: Front-mount guillotine cutter and catch tray keyboard Display Unit
- ZKDU™ keyboard display units for stand-alone printing applications
More Information
| Delivery Option | 15-20 Working Days |
|---|---|
| SKU | ZT51043-T210000Z |
| Brand | Zebra |
| Interface | USB, Serial & Ethernet, Bluetooth |
| Print Resolution | 300 dpi |
| Printer Method | Thermal Transfer |
| Printer Type | Desktop |
| Maximum Print Width | 4.25" max width |
| Label Printers Type | Industrial Printers |
