Fortinet Fortigate FG-101F Network Security Firewall
- Offers secure networking with FortiOS for converged networking and security
- Provides state-of-the-art unparalleled performance with Fortinet’s patented SPU and vSPU processors
- Gartner® Magic Quadrant™ Leaders for both Network Firewalls and WAN Edge Infrastructure supported
- Combines artificial intelligence (AI)-powered security and machine learning (ML) to deliver threat protection at any scale
- Enterprise security with consolidated AI/ ML-powered FortiGuard services integrated
- Next Generation Firewall (NGFW) supported
- Offers dual built-in, non-hot swappable power supplies
- Secure SD-WAN incorporated
Fortinet Fortigate FG-101F Description
Recognised by Gartner® as a leader in both Network Firewalls and WAN Edge Infrastructure in the Magic Quadrant™, the Fortinet Fortigate FG-101F is ideal for demanding environments such as data centres and branch offices, where both security and performance are critical. This device integrates Secure SD-WAN technology, which enables businesses to optimise their wide area network (WAN) for both performance and security. Combining the benefits of traditional WANs with advanced security features allows organisations to create a more flexible, cost-effective, and secure network infrastructure. The integrated Secure SD-WAN also ensures that applications, especially critical ones like VoIP and video conferencing, perform optimally across the WAN while maintaining strong protection against cyber threats.
The Fortinet Fortigate FG-101F supports Next-Generation Firewall (NGFW). This firewall goes beyond the traditional firewall features. It incorporates advanced security services such as deep packet inspection (DPI), intrusion prevention systems (IPS), and secure application control. The supported NGFW allows the FG-101F to provide comprehensive, multi-layered security while ensuring fast and reliable network performance, making it ideal for enterprises that require robust security in addition to network performance. The FortiGate FG-101F is a powerful and versatile solution for modern network security, offering both flexibility and strong protection for complex, distributed IT environments.
Optimised Performance
Fortinet’s SPU (Security Processing Unit) and vSPU (Virtual Security Processing Unit) are specialised hardware processors integrated to optimise the performance of the Fortinet Fortigate FG-101F. These processors handle security tasks such as deep packet inspection, VPN, IPS, and other complex network security functions with high efficiency, ensuring that security does not compromise network speed. Together, the SPU and vSPU provide industry-leading performance, allowing the FortiGate FG-101F to maintain robust security features like intrusion prevention, application control, and web filtering, even under heavy network loads.
Secure Networking
The Fortinet Fortigate FG-101F leverages FortiOS, Fortinet's powerful operating system, to offer a secure networking solution that integrates both networking and security functions into a single, streamlined platform. This integration enables the firewall to handle core networking tasks like routing and switching while providing advanced security features such as threat protection, intrusion prevention, and web filtering. The FortiOS platform is designed to scale as the network grows, meaning businesses can continue to rely on the FG-101F even as their needs change. Whether in small branch offices or large distributed networks, the FortiGate FG-101F operating system (FortiOS) ensures that security remains robust without compromising on performance.
Enterprise-Level Security
Powered by AI and Machine Learning (ML), the Fortinet Fortigate FG-101F integrates FortiGuard services to provide advanced, enterprise-level security. The FortiGuard services offer proactive threat intelligence and dynamic security capabilities that evolve with emerging threats, ensuring continuous protection for your network. It utilises AI and ML to analyse vast amounts of data and identify patterns in network traffic, which helps detect even the most sophisticated and previously unknown threats. The data is automatically updated in real time, allowing the FortiGate FG-101F to stay ahead of attackers without requiring manual intervention.
Uninterrupted Operation
The Fortinet Fortigate FG-101F comes with dual built-in, non-hot swappable power supplies that help ensure uninterrupted operation by providing a backup in case one power supply fails. The inclusion of dual power supplies enhances the FortiGate FG-101F's durability and uptime, ensuring that security and network protection continue without interruption, even in the event of a hardware failure.
What's in the Box?
- Fortinet Fortigate FG-101F
- User Manual
Fortinet Fortigate FG-101F Specifications
Interfaces and Modules
- Hardware Accelerated GE RJ45 Ports: 12
- Hardware Accelerated GE RJ45 Management/ HA/ DMZ Ports: 1 / 2 / 1
- Hardware Accelerated GE SFP Slots: 4
- Hardware Accelerated 10 GE SFP+ FortiLink Slots (default): 2
- GE RJ45 WAN Ports: 2
- GE RJ45 or SFP Shared Ports: 4
- USB Port: 1
- Console Port: 1
- Onboard Storage:0
- Trusted Platform Module (TPM): —
- Bluetooth Low Energy (BLE): —
- Signed Firmware Hardware Switch: —
- Included Transceivers: 0
System Performance — Enterprise Traffic Mix
- IPS Throughput: 2 2.6 Gbps
- NGFW Throughput: 2, 4 1.6 Gbps
- Threat Protection Throughput: 2, 5 1 Gbps
System Performance and Capacity
- IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP): 20 / 18 / 10 Gbps
- Firewall Latency (64 byte, UDP): 4.97 μs
- Firewall Throughput (Packet per Second): 15 Mpps
- Concurrent Sessions (TCP): 1.5 Million
- New Sessions/Second (TCP): 56 000
- Firewall Policies: 10 000
- IPsec VPN Throughput (512 byte): 1 11.5 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels: 2000
- Client-to-Gateway IPsec VPN Tunnels: 16 000
- SSL-VPN Throughput: 1 Gbps
- Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode): 500
- SSL Inspection Throughput(IPS, avg. HTTPS): 1 Gbps
- SSL Inspection CPS (IPS, avg. HTTPS): 1800
- SSL Inspection Concurrent Session (IPS, avg. HTTPS: 135 000
- Application Control Throughput (HTTP 64K): 2.2 Gbps
- CAPWAP Throughput (HTTP 64K): 15 Gbps
- Virtual Domains (Default / Maximum): 10 / 10
- Maximum Number of FortiSwitches Supported: 32
- Maximum Number of FortiAPs(Total / Tunnel): 128 / 64
- Maximum Number of FortiTokens: 5000
- High Availability Configurations: Active-Active, Active-Passive, Clustering
Dimensions and Power
- Height x Width x Length (inches): 1.73 x 17 x 10
- Height x Width x Length (mm): 44 x 432 x 254
- Weight: 7.25 lbs (3.29 kg)
- Form Factor (supports EIA/non-EIA standards): Rack Mount, 1 RU
- AC Power Supply: 100–240V AC, 50/60 Hz
- Power Consumption (Average / Maximum): 26.5 W / 29.5 W
- Current (Maximum): 100V / 1A, 240V / 0.5A
- Heat Dissipation: 100.6 BTU/h
- Redundant Power Supplies: Yes (Default dual non-swappable AC PSU for 1+1 Redundancy)
- Power Supply Efficiency Rating: 80 Plus Compliant
Operating Environment and Certifications
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Storage Temperature: -31°F to 158°F (-35°C to 70°C)
- Humidity: 10% to 90% non-condensing
- Noise Level: 40.4 dBA
- Forced Airflow: Side to Back
- Operating Altitude: Up to 10 000 ft (3048 m)
- Compliance FCC: Part 15B, Class A, CE, RCM, VCCI, UL/cUL, CB, BSMI
- Certifications: USGv6/IPv6
More Information
| Delivery Option | 15-20 Working Days |
|---|---|
| SKU | FG-101F |
| Brands | Fortinet |
| Networking Type | Firewalls |
| Ports | 1x 10/100Mbps |
| Antenna | 2 |
| Compatibility | Linux, Windows |
| Colour | White |
| Condition | New |
